Product Information
Industrial Gigabit Ethernet Media Converter, SM SC connector, 1310 nm, up to 20 km
The perfect converter solution for optical data transmission
- Converts wire-based network signals into fiber optic signals
- High quality and the highest reliability
- 10/100/1000Base-TX to 1000Base-SX
- Ports: 1x RJ45, 1x SC duplex
- Range of up to 20 km
- Wavelength: 1310nm
- Singlemode fiber
- Automatic cable detection - Auto MDI / MDI-X function
- Diagnostic LEDs for status and activity monitoring
- Suitable for 50/125µm, 62.5/125µm, and 100/140µm fiber optic cables (multimode)
- Compact, robust metal housing
- Excellent short circuit protection
The media converters from DIGITUS® are an optimal solution for the migration of copper and fiber optic signals. From now on, you can access the fiber optic technology and transmit fiber optic signals over several kilometers without having to replace your entire network cabling. With our comprehensive range of products, you can respond to your individual needs. The intuitive operation guarantees a quick and easy installation. Many years of experience and a diverse range of services make DIGITUS® a reliable partner for your network technology.
| Network | |
| Maximum data transfer rate | 1000 Mbit/s |
| Converter input interface | 10Base-T, 100Base-T, 1000Base-T |
| Converter output interface | 1000Base-SX |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 1000BASE-T, 100BASE-T |
| Fiber ethernet cabling technology | 1000BASE-SX |
| Data transfer rate | 1000 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 2 |
| Fiber optic connector | SC |
| Performance | |
| Maximum transfer distance | 20000 m |
| Wavelength | 1310 nm |
| Fiber mode structure | Single-mode |
| Fiber cable diameters supported (core/cladding) | 50/125,62.5/125,100/140 æm |
| Design | |
| Internal | No |
| LED indicators | Activity, Status |
| Product colour | Black, Blue |
| Housing material | Metal |
| International Protection (IP) code | IP40 |
| DIN rail mounting | Yes |
| Country of origin | China |
| Warranty | |
| Base Warranty | Non Non |
| Power | |
| Input voltage | 12 - 48 V |
| Power consumption (typical) | 3 W |
| Power over Ethernet (PoE) | No |
| Management features | |
| Digital Diagnostics Monitoring (DDM) | No |
| Weight & dimensions | |
| Width | 118 mm |
| Depth | 92.4 mm |
| Height | 40 mm |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 80 øC |
| Packaging data | |
| Package width | 135 mm |
| Package depth | 54 mm |
| Package height | 165 mm |
| Package volume | 1202.85 cmü |
| Package weight | 558.333 g |
| Packaging content | |
| Quick installation guide | Yes |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
