Media Converter, Singlemode 10/100Base-TX to 100Base-FX, Incl. PSU SC connector, Up to 20km
ITCurry #: M9236305 | Article #: DN-82021-1-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The perfect converter solution for various fiber media
- Distance up to 20km
- Sends data in high quality and additionally provides excellent reliability
- Complies with IEEE 802.3 Ethernet and IEEE 802.3u Fast Ethernet standards
The Media Converters from DIGITUS are the ideal solution for the migration of Copper and Fiber Network Signals. From now on, you are able to access the Fiber Technology and transfer network signals over several kilometers without renewing your whole Network Infrastructure. The huge variety of Products fulfil your individual needs. The intiutive operation guarantees a quick and easy Installation. The Link Fault Pass Through function offers a no-fear-networking. Your Network Administrator will be able to find and solve Network problems easily. Years of Experience and a wide range of products lets DIGITUS become a reliable Partner for your Network.
| Network | |
| Converter input interface | 100Base-TX |
| Converter output interface | 100Base-FX |
| Networking standards | IEEE 802.3, IEEE 802.3u |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Duplex system | Full, Half |
| Performance | |
| Maximum transfer distance | 20000 m |
| Wavelength | 1310 nm |
| Fiber mode structure | Single-mode |
| Fiber cable diameters supported (core/cladding) | 9/125 æm |
| Tx power (min) | -15 dBmW |
| Tx power (max) | -8 dBmW |
| Rx power (min) | -38 dBmW |
| Buffer size | 128 KB |
| Features | |
| Internal | Yes |
| LED indicators | Activity, Link, Status |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
| DC-in jack | Yes |
| Power | |
| Input voltage | 5 V |
| Power consumption (typical) | 2.5 W |
| Power over Ethernet (PoE) | No |
| External power adapter | Yes |
| Weight & dimensions | |
| Weight | 200 g |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 55 øC |
| Packaging content | |
| User guide | Yes |
| Packaging data | |
| Package width | 216 mm |
| Package depth | 60 mm |
| Package volume | 2086.56 cmü |
| Package weight | 450 g |
| Logistics data | |
| Country of origin | China |
| UK Trade Tariff code | 85176200 |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| Dimensions (WxDxH) | 95 x 70 x 26 mm |
| Transmission distance (max) | 20 km |
| Warranty | |
| Base Warranty | Non Non |
