1x4 HDMI Splitter. 4K/60Hz HDCP 2.3. EDID Control
ITCurry #: M9239324 | Article #: DS-55337-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The DIGITUS® HDMI Splitter splits/mirrors your HDMI device’s audio and video signals on 4 TVs, monitors or projectors with a resolution of max. 4K / 60 Hz.
- Distributes an HDMI signal onto 4 TVs/monitors/projectors
- EDID management: Auto/Copy/Downscaler
- Power supply via Micro USB cable (included)
- Max. resolution: 4K/60Hz (4:4:4)
- Video bandwidth: 18 Gbps
- Supports High Dynamic Range (HDR)
- Supports HDCP 2.2
- Supports Deep Color (36-bit)
- HDMI 2.0
The DIGITUS® HDMI Splitter splits your HDMI device’s audio and video signals on 4 TVs, monitors or projectors with a resolution of UHD 4K / 60 Hz. Via EDID management, you can choose from 3 modes (Copy, Auto, Downscaler). The integrated Downscaler supports the display of 4K contents on Full HD displays. Additionally, 4K as well as Full HD displays can be operated simultaneously. Thanks to its Auto-EDID function, the splitter automatically recognizes the connected displays - no manual settings required. The video splitter is supplied with power via the Micro USB cable, e.g. via the source device or a USB charging adapter.
| Ports & interfaces | |
| Video port type | HDMI |
| Video out | 4x HDMI |
| HDMI version | 2.0 |
| Video ports quantity | 4 |
| Connector(s) | Micro USB |
| Consumer Electronics Control (CEC) support | Yes |
| DC-in jack | Yes |
| Features | |
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| Colour depth | 36 bit |
| Maximum refresh rate | 60 Hz |
| HDCP version | 2.3 |
| Extended display identification data (EDID) | Yes |
| High Dynamic Range (HDR) supported | Yes |
| Cable length | 0.75 m |
| Data transfer rate | 18 Gbit/s |
| HDCP | Yes |
| LED indicators | Status |
| Dolby technologies | DTS, Dolby Digital |
| Power | |
| Power consumption (typical) | 5 W |
| Weight & dimensions | |
| Width | 61 mm |
| Depth | 136 mm |
| Height | 14 mm |
| Weight | 182 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 123 mm |
| Package depth | 179 mm |
| Package height | 45 mm |
| Package weight | 310 g |
| Packaging content | |
| Cables included | USB |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 øC |
| Warranty | |
| Base Warranty | Non Non |
