1x4 HDMI Splitter 8K/60Hz (4:4:4) Toslink Stereo EDID Control
ITCurry #: M9239605 | Article #: DS-55340-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The HDMI splitter from DIGITUS® distributes/mirrors audio and video signals from your HDMI device to 4 televisions, screens or projectors with a maximum resolution of 8K/60Hz
- Distributes an HDMI signal to 4 TVs/monitors/projectors
- Audio extractor: Toslink / stereo (3.5 mm) - decoupling and separate playback of the audio signal
- EDID switch / management
- Downscaler function (8K -> 4K or 2K) - scales down the resolution if required, so no display remains black
- Max. Resolution: 8K/60Hz (4:4:4)
- Video bandwidth: 48 Gbps
- Supports High Dynamic Range (HDR)
- Supports HDCP 2.3
- Supports Deep Color (36 bit)
- HDMI 2.1
The HDMI splitter from DIGITUS® distributes/mirrors audio and video signals from your HDMI device to 4 TVs, monitors or projectors in a resolution of UHD 8K/60Hz. Audio signals can also be decoupled via Toslink or 3.5 mm stereo connection and played back separately. The EDID switch can be used to make settings to match the connected displays.
| Ports & interfaces | |
| Video port type | HDMI |
| Video out | 4x HDMI |
| HDMI version | 2.1 |
| Video ports quantity | 5 |
| Audio ports quantity | 1 |
| Digital audio optical out | 1 |
| DC-in jack | Yes |
| Features | |
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 7680 x 4320 pixels |
| HD type | 8K Ultra HD |
| Colour depth | 36 bit |
| Maximum refresh rate | 60 Hz |
| HDCP version | 2.3 |
| Extended display identification data (EDID) | Yes |
| High Dynamic Range (HDR) supported | Yes |
| Data transfer rate | 48 Gbit/s |
| Plug and Play | Yes |
| LED indicators | Yes |
| Power | |
| Power consumption (typical) | 7 W |
| Weight & dimensions | |
| Width | 71 mm |
| Depth | 188 mm |
| Height | 18 mm |
| Weight | 285 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 187 mm |
| Package depth | 207 mm |
| Package height | 56 mm |
| Package weight | 620 g |
| Packaging content | |
| User guide | Yes |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 øC |
| Warranty | |
| Base Warranty | Non Non |
