4x 2 HDMI Matrix Switch 4K/60Hz Scaler EDIDARC HDCP 2.2 18 Gbps
ITCurry #: M9238937 | Article #: DS-55509-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Switch conveniently between up to 4 HDMI sources and 2 playback devices without the trouble of replugging cables and distribute your media content independently on up to 2 playback devices in 4K UHD resolution
- Supports 4K2K/60Hz (4:4:4)
- Video bandwidth: 18 Gbps
- HDCP 2.2 / 1.4
- HDMI 2.0
- EDID management
- ARC (Audio Return Channel)
- Supports downscaling of 4K contents on Full HD (1080p) displays
- Supports Dolby Vision, HDR10+, HLG
- Audio extractor (connection of audio output device via optical/analog connection)
The Digitus® HDMI 4x Matrix Switch, 4K/60Hz distributes media content from up to 4 HDMI sources on up to 2 recording devices (e.g. hard drive recorder) or playback devices (TV, monitor, projector, etc.), simultaneously and independently. Convenient switching via remote control between the HDMI sources and output devices, independently and without the trouble of replugging cables. Thanks to 4K UHD support, you can experience your media content in ultra-high resolution. The perfect and complete HDMI distributor solution whether for professional or commercial use.
| Features | |
| Maximum resolution | 3840 x 2160 pixels |
| Bandwidth | 18 Gbit/s |
| Maximum resolution (HDMI) | 3840 x 2160 pixels |
| HDCP | Yes |
| HDCP version | 1.4/2.2 |
| Extended display identification data (EDID) | Yes |
| EDID management | Yes |
| Design | |
| Housing colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
| Display | |
| Built-in display | No |
| Ports & interfaces | |
| HDMI input ports quantity | 4 |
| HDMI output ports quantity | 2 |
| HDMI version | 2.0 |
| Digital audio optical in | 1 |
| USB connector type | Micro-USB |
| USB ports quantity | 1 |
| Headphone connectivity | 3.5 mm |
| Headphone outputs | 1 |
| DC-in jack | Yes |
| Power | |
| Power consumption (max) | 3.8 W |
| Output current | 1000 mA |
| Output voltage | 12 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Logistics data | |
| Country of origin | China |
| Harmonized System (HS) code | 85299097 |
| Technical details | |
| Package volume | 3750.02 cmü |
| Weight & dimensions | |
| Width | 251 mm |
| Depth | 105 mm |
| Height | 20 mm |
| Weight | 620 g |
| Package width | 309 mm |
| Package type | Box |
| Package depth | 164 mm |
| Package height | 67.3 mm |
| Package weight | 1.09 kg |
| Packaging content | |
| Manual | Yes |
| Mounting brackets included | Yes |
| AC adapter included | Yes |
| Warranty | |
| Base Warranty | Non Non |
