Xpc All-in-one P25n - 11.6in Touch - N100 - 1x So-DIMM Ddr5-4800 - M.2-2280 / 2.5in

ITCurry #: 88702856 | Article #: P25N (FANLESS)
Prijs:
348,08 Excl. btw
Levering in Benelux:
GRATIS Levering.
Nu niet op voorraad. Bel ons!

Verwante producten

slide 6 to 10 of 15

Product Informatie

The Shuttle XPC all-in-one P25N with an 11.6" multi-touch display is positioned as a space-saving POS system or control device for media playback or automation. The adjustable stand allows for flexible viewing and operation angles, while it can also be VESA-mounted to appropriate stands or walls. The front panel is protected from splashing of water and dust according to the IP54 rating. A cable collector box on the back side helps avoid clutter. Thanks to its passive cooling, the system is virtually noise-less, maintenance-free and approved for 24/7 nonstop operation.

Processor
Processorfabrikant Intel
Processormodel N100
Aantal processorkernen 4
Processor aantal threads 4
Maximale turbofrequentie van processor 3,4 GHz
Type processor Ja
Thermal Design Power (TDP) 6 W
Geheugen
Geheugen slots type SO-DIMM
Aantal geheugenslots 1
Maximum intern geheugen 16 GB
Supported memory clock speeds 4800 MHz
Ondersteunde geheugen types DDR5-SDRAM
Geheugen kanaal Eenkanaals
Geheugen voltage 1.1 V
Opslagmedia
Ondersteunde types opslag-drives HDD & SSD
Opslagschijf afmetingen ondersteund 2.5,M.2
Opslag schijf-interface PCI Express, SATA III
Aantal storage drives ondersteund 2
Grafisch
Ingebouwde grafische adapter Ja
Grafische adapter-familie Intel
On-board graphics adapter model Intel© UHD Graphics
Beeldscherm
Beeldschermdiagonaal 29,5 cm (11.6")
Resolutie 1366 x 768 Pixels
Touchscreen Ja
HD type HD
Beeldverhouding 16:9
Helderheid 250 cd/mý
Soort paneel TN
Audio
Ingebouwde luidsprekers Ja
Aantal luidsprekers 1
Gemiddeld vermogen 2 W
Netwerk
Wifi-standaard Wi-Fi 5 (802.11ac)
Wi-Fi-standaarden 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN-controller-model Realtek RTL8821CE
Ethernet LAN Ja
Wifi Ja
LAN controller Intel I226-LM
Bluetooth Ja
Bluetooth-versie 4.2
Poorten & interfaces
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A 6
Aantal HDMI-poorten 1
HDMI versie 2.0b
VGA (D-Sub)poort(en) 1
Microfoon, line-in ingang Ja
Hoofdtelefoonuitgangen 1
Aantal Ethernet LAN (RJ-45)-poorten 1
Aantal COM-poorten 2
Aansluiting voor netstroomadapter Ja
Uitbreidingsmodules
PCI Express slots versie 3.0
Design
Type behuizing Alles-in-een
Kleur van het product Zwart
Type koeling Passief
Aan/uitschakelaar Ja
LED-indicatoren HDD, Stroom
Bevestigingsmogelijkheid voor kabelslot Ja
Kabelslot sleuf type Kensington
VESA-montage Ja
Paneelmontage-interface 75 x 75 mm
Type product All-in-One PC barebone
Prestatie
Aantal ondersteunde processoren 1
BIOS type AMI
Trusted Platform Module (TPM) Ja
Trusted Platform Module (TPM) version 2.0
Audiochip RealTek ALC888S
Warranty
Base Warranty Non Non
Technische details
Certificaten van naleving BSMI, CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, VCCI
Logistieke gegevens
Code geharmoniseerd systeem (HS) 84714100
Software
Ondersteunt Windows Windows 10, Windows 11
Ondersteunt Linux Ja
Inclusief besturingssysteem Nee
Duurzaamheid
Naleving van duurzaamheid Ja
Duurzaamheidscertificaten ENERGY STAR, ErP
Energie
Soort voeding Externe AC-adapter
Netvoeding 65 W
Aantal voedingen 1
AC-ingangsspanning 100 - 240 V
AC-ingangsfrequentie 50/60 Hz
AC-adapter, uitgangsspanning 19 V
AC-adapter, uitgangsstroom 3,42 A
Eisen aan de omgeving
Bedrijfstemperatuur (T-T) 0 - 40 øC
Relatieve vochtigheid in bedrijf (V-V) 10 - 90 procent
Gewicht en omvang
Breedte 299 mm
Diepte 59 mm
Hoogte 207 mm
Gewicht 1,95 kg
Gewicht verpakking 3,14 kg
Inhoud van de verpakking
Inclusief netsnoer Ja
Inclusief AC-adapter Ja
Snelstartgids Ja
Meegeleverde drivers Ja
