Box-PC Barebone BPCAL02-I3 - i3 1215U - max 2x 32 GB DDR5-4800 SO-DIMM - M.2-2280

ITCurry #: 88702880 | Article #: BPCAL02-I3
Prijs:
503,32 Excl. btw
Levering in Benelux:
GRATIS Levering.
Nu niet op voorraad. Bel ons!

Verwante producten

slide 6 to 10 of 15

Product Informatie

Fanless Box-PC with Intel Core processor in a robust chassis
Shuttle's BPCAL02 fanless Box-PC Series is fueled by Intels 12th Generation (Alder Lake) Core processors in a ruggedized box design for high durability. It comes with modular I/O expansion capabilities and various mounting options. With advanced technology and highly flexible design, this industrial PC offers a reliable solution for a wide range of customized requirements in industrial environments.

Processor
Processorfabrikant Intel
Processorfamilie Intel© CoreT i3
Processorgeneratie Intel© 12de generatie CoreT i3
Processormodel i3-1215U
Aantal processorkernen 6
Processor aantal threads 8
Maximale turbofrequentie van processor 4,4 GHz
Prestatiekernen 2
Effici‰nte kernen 4
Performance-core Max Turbo Frequency 4,4 GHz
Efficient-core Max Turbo Frequency 3,3 GHz
Type processor Ja
Processor cache 10 MB
Thermal Design Power (TDP) 15 W
ECC ondersteund door processor Nee
Geheugen
Geheugen slots type SO-DIMM
Aantal geheugenslots 2
Maximum intern geheugen 64 GB
Supported memory clock speeds 4800 MHz
Ondersteunde geheugen types DDR5-SDRAM
Geheugen kanaal Dubbelkanaals
Geheugen voltage 1.1 V
Opslagmedia
Ondersteunde types opslag-drives SSD
Opslagschijf afmetingen ondersteund M.2
SSD-vormfactor M.2
Opslag schijf-interface PCI Express, SATA III
NVMe Ja
Aantal storage drives ondersteund 1
Grafisch
Ingebouwde grafische adapter Ja
Grafische adapter-familie Intel
On-board graphics adapter model Intel© UHD Graphics
Maximum resolutie 3840 x 2160 Pixels
Audio
Ingebouwde luidsprekers Nee
Netwerk
Ethernet LAN Ja
Wifi Nee
LAN controller Intel I226-V
Poorten & interfaces
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A 4
Aantal HDMI-poorten 1
HDMI versie 2.0b
Microfoon, line-in ingang Ja
Hoofdtelefoonuitgangen 1
Aantal Ethernet LAN (RJ-45)-poorten 2
Seri‰le poort(en) 1
Aansluiting voor netstroomadapter Ja
Uitbreidingsmodules
Aantal M.2 (M) slots 1
Design
Type behuizing 2,6L maat pc
Kleur van het product Zwart, Blauw
Type koeling Passief
Materiaal behuizing Aluminium, Staal
VESA-montage Ja
Paneelmontage-interface 75 x 75 mm
Type product Mini PC barebone
Prestatie
BIOS type UEFI AMI
Trusted Platform Module (TPM) Ja
Trusted Platform Module (TPM) version 2.0
Audiochip Realtek ALC888S
Technische details
Certificaten van naleving BSMI, CB, CE, Federal Communications Commission (FCC), RCM, RoHS, VCCI, cTUVus
Logistieke gegevens
Code geharmoniseerd systeem (HS) 84733080
Duurzaamheid
Duurzaamheidscertificaten Certified Enviro Cranberries (CEC), ErP
Energie
Soort voeding Externe AC-adapter
Netvoeding 90 W
Aantal voedingen 1
AC-ingangsspanning 100 - 240 V
AC-ingangsfrequentie 50/60 Hz
AC-adapter, uitgangsspanning 19 V
AC-adapter, uitgangsstroom 4,74 A
Eisen aan de omgeving
Bedrijfstemperatuur (T-T) 0 - 40 øC
Relatieve vochtigheid in bedrijf (V-V) 20 - 80 procent
Gewicht en omvang
Breedte 245 mm
Diepte 169 mm
Hoogte 57 mm
Gewicht 2,85 kg
Inhoud van de verpakking
Inclusief AC-adapter Ja
Warranty
Base Warranty Non Non
