HDMI KVM Extender Set over IP 150m Full HD 1080p
ITCurry #: M9238935 | Article #: DS-55507-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Extends the HDMI signal to up to 150 m and offers KVM functionality to control the signal source via keyboard and mouse on the receiver unit
- Extends the maximum length for HDMI cables to up to 150 m via a simple network cable
- Extension of the signal (unlimited distance) via the existing local network infrastructure or commercial network switches (IP connection)
- Supports video resolutions up to: Full HD (1920x1200/60 Hz, 4:4:4)
- KVM functionality for connection to mouse and keyboard
- Supports CAT 5e, 6, 6A, 7, 8 network cable
- IR transmission
- Compact design for easy and flexible installation
- Sturdy metal housing
The HDMI KVM IP Extender Set comprises a transmitter unit (positioned locally) as well as a receiver unit (positioned at a distance). The HDMI signal can be extended using a network cable ( CAT 5e, 6, 6A, 7, 8 ) up to a maximum distance of 150 m (point-to-point connection). The HDMI signal can also be extended to an unlimited distance using the existing network infrastructure or using standard IP network switches (IP connection). The highest supported video resolution is Full HD (1920x1200/60 Hz, 4:4:4). The set also enables convenient access to a computer (mouse and keyboard) using the USB ports on the receiver unit. The set is perfectly suited for industrial, commercial and public sector applications.
| Kenmerken | |
| Soort | AV-zender & ontvanger |
| Maximum resolutie | 1920 x 1200 Pixels |
| Maximaal bereik | 150 m |
| Elektrostatische ontlading (ESD) bescherming | Ja |
| Bandbreedte | 6,75 Gbit/s |
| Videocompressieformaten | H.265 |
| Materiaal | Metaal |
| Plug and play | Ja |
| HDCP versie | 1.4 |
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| RJ-45 invoer ports | 1 |
| RJ-45 uitgang ports | 1 |
| HDMI in | 1 |
| Aantal HDMI-uitgangen | 1 |
| HDMI versie | 1.4 |
| Aantal USB-aansluitingen | 3 |
| USB-versie | 1.1 |
| USB-connectortype | USB Type-A, USB Type-B |
| Remote (IR) ingang | 1 |
| Remote (IR) uitgang | 1 |
| Energie | |
| Operating voltage | 12 V |
| Stroom | 1 A |
| Stroomverbruik (zender) (max) | 1,4 W |
| Stroomverbruik (ontvanger) (max) | 1,7 W |
| Power over Ethernet (PoE) | Nee |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -10 - 50 øC |
| Gewicht en omvang | |
| Receiver afmetingen (B x D x H) | 67 x 91,5 x 17,5 mm |
| Receiver gewicht | 150 g |
| Transmitter afmetingen (WxDxH) | 67 x 91,5 x 17,5 mm |
| Transmitter gewicht | 155 g |
| Verpakking | |
| Aantal per verpakking | 1 stuk(s) |
| Breedte verpakking | 185 mm |
| Diepte verpakking | 135 mm |
| Hoogte verpakking | 75 mm |
| Gewicht verpakking | 67,5 g |
| Type verpakking | Doos |
| Inhoud van de verpakking | |
| Inclusief AC-adapter | Ja |
| Meegeleverde kabels | USB |
| Gebruikershandleiding | Ja |
| Technische details | |
| Land van herkomst | China |
| Verpakkingsvolume | 1873,12 cmü |
| Logistieke gegevens | |
| Code UK-handelstarief | 85176200 |
| Warranty | |
| Base Warranty | Non Non |
