HDBaseT KVM Extender Set. 150m 4K/60Hz. USB 2.0. PoC. IR. black
ITCurry #: M9239019 | Article #: DS-55526-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The HDBaseT™ HDMI Extender Set enables uncompressed, high-resolution AV signal transmission over large distances and offers KVM functionality (connection of mouse and keyboard)
- Supports HDBaseT™ 1.0 via CAT6A/7/8 cable up to 100 m
- Transmission distance - Full HD (1080p/60Hz): 150 m (max.)
- Transmission distance - UHD (4K/60Hz): 120 m (max.)
- Supports 4K2K/60Hz (4:4:4)
- Video bandwidth: 18 Gbps
- 2x USB 2.0 ports on receiver for connection of webcam, data carrier, touch panel, mouse and keyboard, for example.
- Touch display support / Touch panel back control
- PoC (Power over Cable) - Only the unit requires an external power adapter
- EDID support (2 modes) - 1: Copy - HDMI output receiver / 2: Standard - 1080p, 2 channel
- Bi-directional IR signal transmission
The HDBaseT™ HDMI KVM Extender Set enables uncompressed, high-resolution AV signal transmission over large distances using a CAT6 (or higher) network cable. The maximum transmission distance is 150 m. Thanks to PoC, only one unit needs to be supplied with power by an external power adapter. The receiver unit features two USB 2.0 ports for connection of webcam, data carrier, mouse and keyboard, for example. The set also supports touch displays. Thanks to the touch panel back control, the signal source can also be controlled using finger gestures. Bi-directional IR transmission is also included as a feature.
| Kenmerken | |
| Soort | Zender en ontvanger |
| Connectiviteitstechnologie | Bedraad |
| Maximaal bereik | 150 m |
| Ondersteundende kabel types | Cat6a, Cat7, Cat8 |
| Maximale refresh snelheid | 60 Hz |
| Kleur van het product | Zwart |
| Materiaal | Metaal |
| Gemakkelijk te installeren | Ja |
| Zender | |
| Poorttype zender video | HDMI |
| Aantal displays ondersteund | 1 |
| Poorttype zender lokaal toetsenbord/muis | USB |
| Aantal RJ-45-poorten (zender) | 1 |
| Ontvanger | |
| Poorttype ontvanger lokale video | HDMI |
| Poorttype ontvanger lokaal toetsenbord/muis | USB |
| Aantal RJ-45-poorten (ontvanger) | 1 |
| Poorten & interfaces | |
| USB-poorttype | USB Type-A |
| Aantal USB 2.0-poorten | 5 |
| HDMI versie | 2.0b |
| USB data-overdrachtssnelheden | 480 Mbit/s |
| RJ-45 ports hoeveelheid | 2 |
| Energie | |
| AC-adapter, uitgangsspanning | 24 V |
| AC-adapter, uitgangsstroom | 1 A |
| Stroomverbruik (zender) (max) | 13,2 W |
| Gewicht en omvang | |
| Zender breedte | 14 cm |
| Zender diepte | 6,5 cm |
| Zender hoogte | 1,8 cm |
| Transmitter gewicht | 245 g |
| Receiver breedte | 14 cm |
| Diepte van de receiver | 6,5 cm |
| Receiver hoogte | 1,8 cm |
| Receiver gewicht | 249 g |
| Verpakking | |
| Breedte verpakking | 245 mm |
| Diepte verpakking | 185 mm |
| Hoogte verpakking | 75 mm |
| Gewicht verpakking | 1,09 kg |
| Inhoud van de verpakking | |
| Inclusief AC-adapter | Ja |
| Meegeleverde kabels | IR, USB |
| Gebruikershandleiding | Ja |
| Inclusief bevestigingsbeugel | Ja |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Technische details | |
| Maximum resolutie | 3840 x 2160 Pixels |
| Verpakkingsvolume | 3399,38 cmü |
| Logistieke gegevens | |
| Land van herkomst | China |
| Code UK-handelstarief | 85176200 |
| Warranty | |
| Base Warranty | Non Non |
