1x2 HDMI Splitter 4K/60Hz HDCP 2.2 EDID Control
ITCurry #: M9239570 | Article #: DS-55336
Verwante producten
Product Informatie
The DIGITUS® HDMI Splitter splits/mirrors your HDMI device’s audio and video signals on two TVs, monitors or projectors with a resolution of max. 4K / 60 Hz.
- Distributes an HDMI signal onto 2 TVs/monitors/projectors
- EDID management: Auto/Copy/Downscaler
- Power supply via Micro USB cable (included)
- Max. resolution: 4K/60Hz (4:4:4)
- Video bandwidth: 18 Gbps
- Supports High Dynamic Range (HDR)
- Supports HDCP 2.2
- Supports Deep Color (36-bit)
- HDMI 2.0
The DIGITUS® HDMI Splitter splits your HDMI device’s audio and video signals on two TVs, monitors or projectors with a resolution of UHD 4K / 60 Hz. Via EDID management, you can choose from 3 modes (Copy, Auto, Downscaler). The integrated Downscaler supports the output of 4K contents on Full HD displays. Additionally, a 4K as well as a Full HD display can be operated simultaneously. Thanks to its Auto-EDID function, the splitter automatically recognizes the connected displays - no manual settings required. The video splitter is supplied with power via the Micro USB cable, e.g. via the source device or a USB charging adapter.
| Poorten & interfaces | |
| Aansluiting video | HDMI |
| Video uit | 2x HDMI |
| HDMI versie | 2.0 |
| Hoeveelheid Video ports | 3 |
| Aansluiting voor netstroomadapter | Ja |
| Kenmerken | |
| Kleur van het product | Grijs |
| Materiaal behuizing | Metaal |
| Maximum resolutie | 3840 x 2160 Pixels |
| HD type | 4K DCI |
| Kleurdiepte | 36 Bit |
| Maximale refresh snelheid | 60 Hz |
| HDCP versie | 2.2 |
| Extended display identification data (EDID) | Ja |
| HDR-ondersteuning | Ja |
| Overdrachtssnelheid | 18 Gbit/s |
| HDCP | Ja |
| LED-indicatoren | Ja |
| Dolby technologie‰n | DTS, Dolby Digital |
| Energie | |
| Stroomverbruik (typisch) | 5 W |
| Stroomvoorziening via USB | Ja |
| Gewicht en omvang | |
| Breedte | 90 mm |
| Diepte | 44 mm |
| Hoogte | 14 mm |
| Gewicht | 90 g |
| Verpakking | |
| Aantal per verpakking | 1 stuk(s) |
| Type verpakking | Doos |
| Inhoud van de verpakking | |
| Meegeleverde kabels | Micro-USB |
| Logistieke gegevens | |
| (Buitenste) hoofdverpakking breedte | 270 mm |
| (Buitenste) hoofdverpakking lengte | 488 mm |
| (Buitenste) hoofdverpakking hoogte | 214 mm |
| (Buitenste) hoofdverpakking brutogewicht | 14,7 kg |
| (Buitenste) hoofdverpakking inhoud | 28196,64 cmü |
| Hoeveelheid per (buitenste) hoofdverpakking | 100 stuk(s) |
| Warranty | |
| Base Warranty | Non Non |
