Specifications |
Data transmission |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Maximum data transfer rate |
1774 Mbit/s |
Performance |
2.4 GHz |
Yes |
5 GHz |
Yes |
Auto MDI / MDI-X |
Yes |
Spread spectrum method |
DSSS,OFDM,OFDMA |
Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az |
Modulation |
16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Maximum data transfer rate |
1774 Mbit/s |
MIMO type |
Multi User MIMO |
DESPITE |
Yes |
Wireless LAN features |
Modulation |
16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Network |
Spread spectrum method |
DSSS,OFDM,OFDMA |
Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az |
Security |
Cable lock slot |
Yes |
Security algorithms |
WPA3,WPA,WPA2 |
Features |
2.4 GHz |
Yes |
5 GHz |
Yes |
Auto MDI / MDI-X |
Yes |
Spread spectrum method |
DSSS,OFDM,OFDMA |
Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az |
Modulation |
16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Maximum data transfer rate |
1774 Mbit/s |
MIMO type |
Multi User MIMO |
DESPITE |
Yes |
Maximum data transfer rate (2.4 GHz) |
574 Mbit/s |
Maximum data transfer rate (5 GHz) |
1200 Mbit/s |
Ports & interfaces |
USB connector type |
USB Type-A |
USB 2.0 ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
1 |
Power |
Power consumption (max) |
16.5 W |
Power over Ethernet (PoE) |
Yes |
Design |
Placement |
Ceiling, Wall |
Product colour |
White |
Cable lock slot |
Yes |
Cable lock slot type |
Kensington |
Antenna |
Antenna type |
Internal |
Antennas quantity |
2 |
Antenna direction type |
Omni-directional |
Antenna features |
Integrated antenna |
Operational conditions |
Operating relative humidity (H-H) |
5 - 93% |
Operating temperature (T-T) |
0 - 50 °C |
Storage temperature (T-T) |
-40 - 70 °C |
Storage relative humidity (H-H) |
5 - 93% |
Weight & dimensions |
Width |
160 mm |
Depth |
161 mm |
Weight |
500 g |
Height |
37 mm |
|
