Aruba AP-504 (US) dual radio 2x2:2 802.11ax external antenna unified campus AP

ITCurry #: 1171ZK21 | Article #: R2H23A
Price:
595.11 Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Email us for assistance

Related products

slide 7 to 11 of 14

Product Information

HPE Aruba Networking 500 Series Campus Access Points deliver cost-effective Wi-Fi 6 coverage for indoor environments such as mid-sized offices, schools, and retail spaces where fewer people are on the network at the same time. With 1.49 Gbps maximum combined data rate, the 500 Series delivers reliable Wi-Fi for medium density environments and is supported by HPE Aruba Networking Central, AI-powered management that simplifies and improves IT operations across branch, remote office, campus, data center, and IoT networks with a single point of visibility and control. The 500 Series is Wi-Fi CERTIFIED™ and supports Wi-Fi 6 (802.11ax) features: OFDMA for multi-user efficiency, target wake time (TWT) to extend the battery life of connected IoT devices, and WPA3 and Enhanced Open for greater password and guest security. The 500 Series includes a limited lifetime warranty.

What is new supporting point:
Dynamic Segmentation and policy enforcement firewalls automatically enforce consistent policies across wired and wireless networks, enhancing user and device security.
Entry level Wi-Fi 6 access points provide up to 1.49 Gbps maximum combined data rate.
Support for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
IoT-ready with built-in [1] Bluetooth 5 and Zigbee support.
Built-in technology that resolves sticky client issues and improves performance of mobile Wi-Fi clients.
Available in optional eco-friendly 10-packs.

Features
2.4 GHz Yes
5 GHz Yes
Maximum data transfer rate 1774 Mbit/s
Maximum data transfer rate (2.4 GHz) 574 Mbit/s
Maximum data transfer rate (5 GHz) 1200 Mbit/s
Ethernet LAN data rates 10,100,1000 Mbit/s
Networking standards IEEE 802.11ax
Auto MDI/MDI-X Yes
MIMO Yes
MIMO type Multi User MIMO
Spread spectrum method DSSS, OFDM, OFDMA
Modulation 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Security
Security algorithms WPA3, WPA, WPA2
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
USB 2.0 ports quantity 1
USB connector type USB Type-A
Power
Power over Ethernet (PoE) Yes
Design
Placement Ceiling, Wall
Product colour White
Cable lock slot Yes
Cable lock slot type Kensington
Antenna
Antenna type External
Antenna connector type RP-SMA
Number of connectors 2
Certificates
Compliance certificates Low Voltage Directive (LVD)
Certification None
Weight & dimensions
Width 160 mm
Depth 161 mm
Height 37 mm
Weight 500 g
Operational conditions
Operating relative humidity (H-H) 5 - 93%
Operating temperature (T-T) 0 - 50 øC
Storage temperature (T-T) -40 - 70 øC
Storage relative humidity (H-H) 5 - 93%
Warranty
Base Warranty Non Non
