1.25 Gbps SFP Module, Up to 20km Singlemode, LC Duplex Connector, Industrial Ver. 1000Base-LX, 1310nm
ITCurry #: M9236281 | Article #: DN-81011-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The plug and play fiber connection
- The Plug & Play fiber optic link enables quick installation
- Sends data in high quality and additionally provides excellent reliability
- Distance up to 20 km at a maximum data rate of 1.25Gbps
- Operating temperature: -40 °C - +85 °C
The DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch, converter to switch, converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers.
Performance | |
SFP transceiver type | Fiber optic |
Maximum data transfer rate | 1250 Mbit/s |
Interface type | mini-GBIC/SFP |
Single-mode fiber (SMF) supported | Yes |
Fiber optic connector | LC |
Maximum transfer distance | 20000 m |
Wavelength | 1310 nm |
Tx power (min) | -8 dBmW |
Tx power (max) | -3 dBmW |
Rx power (min) | -24 dBmW |
Ethernet interface type | Gigabit Ethernet |
Networking standards | IEEE 802.3z |
Cabling technology | 1000Base-LX |
Duplex system | Full |
Digital Diagnostics Monitoring (DDM) | No |
Fiber ports quantity | 1 |
Features | |
Product colour | Metallic |
Plug and Play | Yes |
Hot-Plug support | Yes |
Easy to install | Yes |
Brand compatibility | MSA Compliant |
Packaging content | |
Quantity per pack | 1 pc(s) |
Packaging data | |
Package width | 120 mm |
Package depth | 30 mm |
Package volume | 324 cmü |
Package weight | 35.417 g |
Logistics data | |
UK Trade Tariff code | 85176200 |
Harmonized System (HS) code | 85369010 |
Country of origin | China |
Warranty | |
Base Warranty | Non Non |
