Vfmf50d Motorised Height Adjustable Dual Display Floor Stand
ITCurry #: Q3823724 | Article #: VFM-F50/D-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Need to install a Microsoft Teams or Zoom room? Vision’s VFM-F50 Dual floor stand makes it easy to install two displays on one mount. This kit comprises the wall-fixing F50 with a dual-display adaptor rail, and a second wall mount.
The F50 has motorised height adjustment so with a one-button press, you can raise it to so you can raise it high for bigger rooms, or lower it to align with the height of a meeting table.
2 x Displays
Support two displays from 55" to 86". Each display can weight up to 45 kg. The aluminium rail comes in three parts and allows side to side adjustment of the displays.
Camera Shelf
A centre shelf is included. It can support a camera above, below, or in the centre between the two screens. If the camera is smaller like the Logitech Brio, the platform part of the shelf assembly can be left off to make it less obtrusive.
Putting the camera at the centre of the two screens creates a more natural impression of eye contact for the remote participants.
SWL 95 kg (209 lbs)
The F50 uses heavy-gauge components to take the weight, and a linear drive with twin drive shafts to power the vertical motion. The weight of all displays combined cannot exceed this.
Three cartons
This kit contains 1 x VFM-F50 floor stand, 1 x VFM-F50_DL rail accessory, and 1 x VFM-W8X6 wall mount. If you need a different combination you can order each part separately.
Wired Control or RS-232
A wired remote control is included with simple up and down functions. It fixes to the rear of the display with an adhesive sticker. Alternatively, use a control system to activate the F50 via RS-232 and add pre-set positions, and upper and lower limits.
Highly Adjustable Wall Brackets
We include two brackets to fix the lower part of the F50 to the wall, which slide up and down slots so they can be located at just the ideal height. These secure the column almost flush to the wall or standing off up to 140 mm (5.5?). Note: if only one wall bracket can be fixed to a load bearing structure, the column must be fixed to the floor.
Feet or Fixed
Adjustable feet are included to make it easy to adjust level, or remove the feet and fix the column to the floor.
Hide Mess
Generous cable entry holes make routing cables quick and easy. The front cover can be removed for end users to easily access anything they need. There is also plenty of space to hide cables, media players, mini PCs, and power distribution boards inside the column.
Landscape or Portrait
Vision's VESA mounts support portrait or landscape orientation.
800 mm / 31.5" Motorised Height Adjustment
The height of the display can be altered to suit the audience thanks to motorised height adjustment. The telescopic column movement range is 800 mm / 31.5?.
Increased Safety
If there is obstruction under the display as it is lowered, the weight of the display simply rests on top of the obstruction. It does not pull down and crush the obstruction. There is safety sensor which sensors obstacles and will stop the motor.
| Montage | |
| Minimale schermgrootte | 139,7 cm (55") |
| Maximale gewichtscapaciteit | 95 kg |
| Maximale schermgrootte | 2,18 m (86") |
| Montage interface compatibiliteit (min) | 300 x 300 mm |
| Montage interface compatibiliteit (max) | 800 x 600 mm |
| Paneelmontage-interface | 300 x 400,300 x 300,400 x 200,400 x 400,400 x 300,400 x 600,500 x 400,500 x 500,600 x 400,600 x 600,600 x 500,800 x 400,800 x 500,800 x 600,1600 x 600 |
| Aantal displays ondersteund | 2 |
| Montagewijze | Muur |
| Ergonomie | |
| In hoogte verstelbaar | Ja |
| Type hoogteverstelling | Electrisch |
| Wielen | Nee |
| Hijssnelheid | 16 mm/sec |
| Design | |
| Kleur van het product | Zwart |
| Materiaal behuizing | Aluminium, Staal |
| Energie | |
| AC-ingangsspanning | 110 - 230 V |
| Lengte stroomkabel | 2,5 m |
| Technische details | |
| Hefgewicht (max) | 95 kg |
| Aantal per verpakking | 1 stuk(s) |
| Gemakkelijk te installeren | Ja |
| Model | Landschap/portret |
| Naleving van duurzaamheid | Ja |
| Certificaten van naleving | CE, Federal Communications Commission (FCC), Laagspanningsrichtlijn (LVD), RoHS, WEEE |
| Inhoud van de verpakking | |
| Meegeleverde kabels | Stroom |
| Montagebeugels meegeleverd | Ja |
| Aantal montagebeugels | 2 |
| Inclusief bouten | Ja |
| Moeren inbegrepen | Ja |
| Gewicht en omvang | |
| Breedte | 845 mm |
| Diepte | 11,3 cm |
| Diepte (max) | 16,7 cm |
| Hoogte | 2235 mm |
| Verpakking | |
| Aantal per pakket | 1 paar/paren |
| Afmetingen pakket 1 (BxDxH) | 1112 x 422 x 198 mm |
| Gewicht pakket 1 | 38,5 kg |
| Afmetingen pakket 2 (B x D x H) | 884 x 224 x 237 mm |
| Gewicht pakket 2 | 12,1 kg |
| Afmetingen verpakking 3 (B x D x H) | 880 x 235 x 40 mm |
| Gewicht pakket 3 | 6,8 kg |
| Warranty | |
| Base Warranty | Non Non |
