Geist Rack PDU Switched 0U input IEC60309 230V 32A outputs (20)C13 (4)C19
ITCurry #: N6415103 | Article #: VP8953-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The Vertiv Geist Switched Rack PDU VP8953 is a 32A, 230V, 0U vertical rack power distribution unit (PDU) with input power monitoring and outlet level switching. The VP8953 has (20) locking IEC C13 and (4) locking IEC C19 outlets, and a 1P+N+E (IP44) plug providing 7.3kW in power capacity. This Switched PDU allows you to turn off receptacles to avoid accidental overloads and power cycle equipment remotely to reboot unresponsive critical IT equipment. The hot-swappable Interchangeable Monitoring Device (IMD) displays current on the local LED display. Visible Light Communication (VLC) technology allows you to view complete power usage data locally from a mobile device with the Vertiv rPDU Scanner app. Each rack mount PDU undergoes individual testing for functionality to ensure your network is powered by a reliable smart power strip. The unit comes with a three-year warranty that can be extended to five years if registered within 120 days of purchase.
| Design | |
| PDU types | Geschakeld |
| Soort | Eenfasig |
| Rackcapaciteit | 0U |
| Montage | Verticaal |
| Kleur van het product | Zwart |
| Poorten & interfaces | |
| Aantal AC uitgangen | 24 AC-uitgang(en) |
| Stekker | IEC 60309 |
| Stopcontacttypes | C13 stekker, C19 stekker |
| Output-aansluitingen | 20 x C13 & 4 x C19 |
| Kenmerken | |
| LED-indicatoren | Ja |
| Snoerlengte | 3 m |
| Certificering | CE, RoHS, CB certificate, FCC Part 15 class A, UL, c-UL |
| Beheerfuncties | |
| Monitoring | Stroom, Stroom, Spanning |
| Beheerplatform | Web UI, DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RSTP, SSH, SMTP, (v1/v2c/v3), Syslog, CSV datalog, JSON API, JSON datalog |
| Energie | |
| Nominale input voltage | 230 V |
| AC-ingangsfrequentie | 50 Hz |
| Stroom (max.) | 32 A |
| Laad-capaciteit | 7300 VA |
| Gewicht en omvang | |
| Breedte | 1683 mm |
| Diepte | 51 mm |
| Afmetingen (B x D x H) | 1683 x 51 x 66 mm |
| Hoogte | 66 mm |
| Gewicht | 9,07 kg |
| Verpakking | |
| Breedte verpakking | 18 mm |
| Diepte verpakking | 223 mm |
| Hoogte verpakking | 159 mm |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 50 øC |
| Technische details | |
| Duurzaamheidscertificaten | RoHS |
| Compliance certificates | RoHS |
| Warranty | |
| Base Warranty | Non Non |
