Wireless Mu-mimo Gigabit Eap225 Outdoor Access Point Ac1200 White
ITCurry #: P6042844 | Article #: EAP225-OUTDOOR-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
11AC Wave 2 Makes Wi-Fi Go Further
Omada
EAP225-Outdoor
Gigabit Wi-Fi Speeds with MU-MIMO Technology
EAP225-Outdoor supports simultaneous dual band speed of up to 1200Mbps. Outfitted with the latest 802.11ac Wave 2 MU-MIMO technology, EAP225-Outdoor can communicate with multiple clients at the same time which making it ideal for high density environment.
Excellent Hardware Designs
With special design of its antenna, appearance, power options and installation methods, EAP225-Outdoor can perfectly fit for different scenarios both indoors and outdoors.
Detachable Antennas
EAP225-Outdoor is designed with 2 Omni-directional detachable antennas, which means other antennas can also be attached for your specific demands.
Delicate Appearance Even Better for Indoor Applications
EAP225-Outdoor is just similar to a cellphone, with dimension: 8.5 × 1.8 × 1.1in. (215 × 46 × 27mm)
Multiple PoE Options for Easy Installation
EAP225-Outdoor supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter.
Excellent Hardware Designs
With special design of its antenna, appearance, power options and installation methods, EAP225-Outdoor can perfectly fit for different scenarios both indoors and outdoors.
Flexible Deployment
EAP225-Outdoor can be easily installed on a wall or to a pole with the mounting kits provided.
Wi-Fi That Goes the Distance
With high transmission power and high gain omnidirectional antennas, EAP225-Outdoor provides stable wireless coverage at a range up to 200m+* at 2.4GHz and 300m+* at 5GHz in outdoor settings.
Specially Designed Weatherproof Enclosure for
Outdoor Environment
Rated as IP65 during Ingress Protection testing, a resilient weatherproof enclosure protects the access points against harsh outdoor condition.
Efficient Centralized Network Management
With Omada Controller software, small and medium-sized businesses can take command of hundreds of indoor and outdoor access points all from a single location. It’s network management as it should be - efficient and intuitive.
| Kenmerken | |
| 2,4 GHz | Ja |
| 5 GHz | Ja |
| 6 GHz | Nee |
| Maximale overdrachtssnelheid van gegevens | 867 Mbit/s |
| Maximale overdrachtssnelheid van gegevens (2.4 GHz) | 300 Mbit/s |
| Maximale overdrachtssnelheid van gegevens (5 GHz) | 867 Mbit/s |
| Ethernet LAN, data-overdrachtsnelheden | 10,100,1000 Mbit/s |
| Frequentieband | 2.4 - 5 GHz |
| Netwerkstandaard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u |
| MIMO | Ja |
| MIMO-type | Multi User MIMO |
| Wifi Multimedia (WMM)/(WME) | Ja |
| Rate limiting | Ja |
| Bandbreedteaansturing | Ja |
| Airtime Fairness (ATF) | Ja |
| Quality of Service (QoS) | Ja |
| Beveiliging | |
| Ondersteunde beveiligingsalgoritmen | WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
| Aantal SSID-ondersteuningen | 16 |
| Remote Authentication Dial-In User Service (RADIUS) | Ja |
| Beheerfuncties | |
| Web-gebaseerd management | Ja |
| Syslog | Ja |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Energie | |
| Power over Ethernet (PoE) | Ja |
| Type Power over Ethernet (PoE) ondersteunt | Active PoE, Passive PoE |
| Spanning | 24 V |
| Stroomverbruik (typisch) | 10,5 W |
| Design | |
| Plaatsing | Plafond, Muur |
| Kleur van het product | Wit |
| Reset button | Ja |
| Antenne | |
| Soort antenne | Extern |
| Type antennerichting | Omni-directioneel |
| Antennefuncties | Afneembare antenne |
| Antennas quantity | 2 |
| Antenne versterkingsniveau (max) | 4 dBi |
| Certificaten | |
| Certificering | CE?FCC?RoHS |
| Gewicht en omvang | |
| Breedte | 214,9 mm |
| Diepte | 46 mm |
| Hoogte | 26,7 mm |
| Verpakking | |
| Breedte verpakking | 270 mm |
| Diepte verpakking | 140 mm |
| Hoogte verpakking | 100 mm |
| Gewicht verpakking | 640 g |
| Inhoud van de verpakking | |
| Aantal per verpakking | 1 stuk(s) |
| Inclusief AC-adapter | Ja |
| Inclusief PoE-adapter | Ja |
| Montage gereedschap | Ja |
| Snelstartgids | Ja |
| Eisen aan de omgeving | |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 procent |
| Bedrijfstemperatuur (T-T) | -30 - 70 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Luchtvochtigheid bij opslag | 5 - 90 procent |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
