Omada Gigabit VPN Router
Professional, Secure, and Reliable Gigabit VPN Router
Omada SDN—The Smarter Cloud Solution for Business Networking
As the gateway that seamlessly integrates into the Omada Software Defined Networking (SDN) platform, ER605 allows for remote and centralized management, anywhere, anytime. Standalone management via the Web UI or app is also available to maximize convenience.
Up to Three WAN Gigabit Ports & One USB WAN for Mobile Broadband
Two freely interchangeable ports allow the router to support up to three WAN ports for various Internet access requirements. The multi-WAN Load Balancing function distributes data streams according to the bandwidth proportion of every WAN port to raise the utilization rate of multi-line broadband.
Mobile broadband via 4G/3G modem by connecting to the USB port is also supported for WAN backup.
High-Security and High-Performance VPN
ER605 supports IPSec/PPTP/L2TP VPN over IPSec/SSL protocols. One-click auto IPSec VPN* greatly simplifies VPN configuration and facilitates network management and deployment. It also secures and encrypts private site-to-site data communications traveling over the internet. This version improves VPN performance by 4–5 times thanks to the open line of communication with Omada's user base.
Abundant Security Features
Powerful Firewall
Advanced firewall policies protect your network and data.
Convenient VLAN Support
Create virtual network segments for enhanced security and simplified network management.
DoS Defense
Automatically detects and blocks Denial of Service (DoS) attacks such as TCP/UDP/ICMP Flooding, Ping of Death, and other related threats.
IP/MAC/URL Filtering
Forcefully prevent viruses and attacks from intruders.
IP-MAC Binding
Reserves static IP assignment for clients to defend against ARP attacks and spoofing.
One-Click ALG Activation
One-Click ALG Activation for applications such as FTP, H323, SIP, IPSec and PPTP.
Internet Access Management Strategy
Administrators can moderate users' online behavior and easily specify employees' internet access rights and strategies via IP/MAC/URL Filtering and Access Control List (ACL). Captive Portal authentication facilitates network resource control by capturing, authenticating, and classifying user access. Appropriate network resources can also be allocated for particular users or guests.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status, and manage clients, all from the convenience of a mobile device.
| WAN-verbinding | |
| Ethernet WAN | Ja |
| DSL WAN | Nee |
| SIM-kaartsleuf | Nee |
| 3G/4G USB modem compatibiliteit | Nee |
| Netwerk | |
| Netwerkstandaard | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Ethernet interface type | Gigabit Ethernet |
| Bekabelingstechnologie | 10/100/1000Base-T(X) |
| Ethernet LAN, data-overdrachtsnelheden | 10,100,1000 Mbit/s |
| VLAN=ondersteuning | Ja |
| Verkeerscontrole | Ja |
| Op beleid gebaseerde routering | Ja |
| Concurrent connections | 150000 |
| Beheerfuncties | |
| Web-gebaseerd management | Ja |
| Universal Plug and Play ( UPnP ) | Ja |
| Reset button | Ja |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten | 5 |
| Aantal USB-aansluitingen | 1 |
| Protocollen | |
| DMZ support | Ja |
| Routing protocols | RIP-1, RIP-2 |
| Beheerprotocollen | Telnet |
| DHCP client | Ja |
| DHCP server | Ja |
| Ondersteunde netwerkprotocollen | TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP |
| Ondersteunde protocollen | IPsec/PPTP/L2TP |
| Beveiliging | |
| Ondersteunde beveiligingsalgoritmen | 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1 |
| Firewall | Ja |
| Autenticatiemethode | SHA-1, MD5 |
| URL- filtering | Ja |
| DoS aanval preventie | Ja |
| ARP-aanvalspreventie | Ja |
| Network address translation (NAT) | Ja |
| System event log | Ja |
| VPN tunnels quantity | 20 |
| VPN eigenschappen | 20 IPsec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm IKEv1/v2 MD5, SHA1 Authentication Algorithm NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) PPTP VPN Server 10 PPTP VPN Clients 16 Tunnels PPTP with MPPE Encryption L2TP VPN Server 10 L2TP VPN Clients 16 Tunnels L2TP over IPSec OpenVPN Server 10 OpenVPN Clients 16 OpenVPN Tunnels |
| NAT functionality | One-to-One NAT Multi-Net NAT Virtual Server Port Triggering NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG, UPnP |
| Technische details | |
| Duurzaamheidscertificaten | RoHS |
| Compliance certificates | RoHS |
| Kenmerken | |
| Flash memory | 128 MB |
| Intern geheugen | 256 MB |
| Intern geheugentype | DRAM |
| Ondersteunt Windows | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Ondersteunt Mac-besturingssysteem | MacOS |
| Ondersteunt Linux | Ja |
| Certificering | CE, FCC, RoHS |
| Design | |
| Kleur van het product | Zwart |
| Rack-montage | Ja |
| Rackcapaciteit | 1U |
| LED-indicatoren | Activiteit, LAN, Systeem, USB, WAN |
| Energie | |
| Stroomverbruik (typisch) | 7,94 W |
| Type stroombron | AC |
| AC-ingangsspanning | 120 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 procent |
| Luchtvochtigheid bij opslag | 5 - 90 procent |
| Gewicht en omvang | |
| Breedte | 158 mm |
| Diepte | 101 mm |
| Hoogte | 25 mm |
| Verpakking | |
| Meegeleverde kabels | AC |
| Gebruikershandleiding | Ja |
| Snelstartgids | Ja |
| Snelle installatiehandleiding | Ja |
| Breedte verpakking | 190 mm |
| Diepte verpakking | 254 mm |
| Hoogte verpakking | 60 mm |
| Gewicht verpakking | 650 g |
| Warranty | |
| Base Warranty | Non Non |
