UP SuperServer SYS-511E-WR - GOLD X13 UP WIO 1U 4510 64G 960G 1G HF R
ITCurry #: 7851A605 | Article #: SYS-511E-WR-G1
Verwante producten
Product Informatie
Supermicro WIO SuperServer® systems allow users to select from a wide range of I/O options to optimize the storage and networking solutions to best fit their applications. In addition to enabling customizable configurations and optimization for a wide range of application requirements, Supermicro WIO SuperServers also provide attractive cost advantages and investment protection.
The Supermicro SYS-511E-WR WIO SuperServer® supports 4th Gen Intel® Xeon® Scalable Processors (up to 52 cores) and 2TB ECC DDR5-4800MT/s RDIMM memory in 8 DIMM slots. The SYS-511E-WR includes 4 hot-swappable 3.5” SATA drive bays which makes changing hard drives easy without needing to open up the server. In addition, this WIO server supports up to 2 SuperDOM with built-in power and a M.2 slot, which is designed for use as a boot drive, backup recovery device, license drive, or OS installation device (replacing CD/DVD-ROMs).
| Processor | |
| Processorfabrikant | Intel |
| Processorfamilie | Intel© Xeon© Silver |
| Processormodel | 4510 |
| Frequentie van processor | 2,4 GHz |
| Maximale turbofrequentie van processor | 4,1 GHz |
| Aantal processorkernen | 12 |
| Processor cache | 30 MB |
| Chipset moederbord | Intel C741 |
| Processor socket | LGA 4677 (Socket E) |
| Geheugen | |
| Intern geheugen | 64 GB |
| Intern geheugentype | DDR5-SDRAM |
| Geheugenslots | 8x DIMM |
| ECC | Ja |
| Kloksnelheid geheugen | 5600 MHz |
| Maximum intern geheugen | 2 TB |
| Opslagmedia | |
| Totale opslagcapaciteit | 960 GB |
| Aantal ge‹nstalleerde SSD's | 1 |
| SSD capaciteit | 960 GB |
| SSD interfaces | PCI Express 4.0 |
| NVMe | Ja |
| SSD-formaat | M.2 |
| RAID support | Ja |
| Soorten RAID | 0, 1, 5, 10 |
| Hot-swap | Ja |
| Grafisch | |
| Ingebouwde grafische adapter | Nee |
| Netwerk | |
| LAN controller | Intel I210 |
| Ethernet LAN | Ja |
| Ethernet interface type | Gigabit Ethernet |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten | 2 |
| Aantal USB 2.0-poorten | 2 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 2 |
| VGA (D-Sub)poort(en) | 1 |
| Uitbreidingsmodules | |
| PCI Express x8 (Gen 5.x) sleuven | 1 |
| PCI Express x16 (Gen 5.x) sleuven | 2 |
| Design | |
| Type behuizing | Rack (1U) |
| Kleur van het product | Zwart |
| Type koeling | Actief |
| Prestatie | |
| BIOS type | AMI |
| Trusted Platform Module (TPM) | Ja |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Inclusief besturingssysteem | Nee |
| Energie | |
| Redundante voeding | Ja |
| Netvoeding | 860 W |
| Aantal ondersteunde redundante voedingen | 2 |
| Ingangsfrequentie voeding | 50 - 60 Hz |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 10 - 35 øC |
| Temperatuur bij opslag | -30 - 60 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 8 - 90 procent |
| Luchtvochtigheid bij opslag | 8 - 90 procent |
| Gewicht en omvang | |
| Breedte | 437 mm |
| Diepte | 650 mm |
| Hoogte | 43 mm |
| Gewicht | 9,75 kg |
| Breedte verpakking | 596,9 mm |
| Diepte verpakking | 856 mm |
| Hoogte verpakking | 215,9 mm |
| Gewicht verpakking | 15,5 kg |
| Warranty | |
| Base Warranty | Non Non |
