Compact Camera Srg-xb25 60mpix 25x Optical Zoom Box-style Remote Black
ITCurry #: 5320Y202 | Article #: SRG-XB25B-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Stream crisp, detail-packed 4K 60p video with this high quality remote camera that features a powerful 25x optical zoom lens for frame-filling close-ups in larger venues.
The SRG-XB25 high-zoom BOX camera draws on decades of Sony’s professional imaging know-how to suit a wide range of content creation applications. It’s ideal for capturing and streaming impressive 4K pictures in environments including seminar rooms, lecture theatres, virtual production studios, government/parliament buildings and houses of worship. The cost-effective SRG-XB25 is particularly appealing for multi-camera shooting set-ups, where high quality images are required without the need for a team of dedicated camera operators. The integrated lens with powerful 25x optical zoom captures frame-filling close-ups of speakers and presenters, even when the camera’s installed at the back or larger auditoriums and public venues. The SRG-XB25 fits seamlessly into all-IP production environments, with a single Ethernet cable carrying power, streaming video and camera control signals. Ideal for lecture capture applications, the SRG-XB25 partners seamlessly with the REA-C1000 Edge Analytics Appliance. For example, the camera’s powerful 25x zoom captures the speaker’s gestures and handwriting in large classrooms or teaching spaces, allowing REA-C1000 to deliver what the customer requires.
Robust, stylish and compact
Measuring just 70.9 x 80.1 x 178.3 mm and weighing 872 g, the SRG-XB25 can be readily integrated into any environment. Upper and lower tripod mounts increase installation flexibility. Rear panel guards assure extra robustness, and the large, easy-to-read tally lamp is useful in multiple camera set-ups.
Powerful 25x optical zoom
The integrated autofocus lens with 25x optical zoom plus additional digital zoom assures ultra-clear, powerful close-ups of presenters or audience members.
Easy IP connectivity, single-cable installation
Camera control, PoE and streaming video output are carried over a single Ethernet cable, reducing installation costs and simplifying integration in space-restricted or hard-to-reach locations. Full IP integration includes support for Real Time Streaming Protocol (RTSP) and Real Time Messaging Protocol (RTMP). Support for NDI |HX is also available via an optional licence.
High quality 4K 60p images
The camera’s 1/2.5-type Exmor R CMOS sensor captures smooth, crisply detailed 4K 60p video with excellent low-light sensitivity.
Broadcast-style tally light
The camera-mounted tally light gives visual confirmation to the lecturer or presenter when the camera is active. The horizontal bar-style light is easily visible to both performer/presenter and director.
Audio input
Connect an external microphone or line-level source to capture clear pictures plus sound in lecture theatres and meeting rooms or on reality TV shows.
| Prestatie | |
| Soort | IP-beveiligingscamera |
| Ondersteuning voor plaatsing | Binnen |
| Connectiviteitstechnologie | Bedraad |
| Design | |
| Vormfactor | Doos |
| Kleur van het product | Zwart |
| Camera | |
| Minimale belichting | 1 Lux |
| Kijkhoek lens, horizontaal | 68ø |
| Camera sluitertijd | 1 - 1/10000 s |
| Beeldsensor | |
| Aantal sensoren | 1 |
| Omvang optische sensor | 25,4 / 1,25 mm (1 / 1.25") |
| Type beeldsensor | CMOS |
| Lenssysteem | |
| Zoomcapaciteit | Ja |
| Optische zoom | 25x |
| Digitale zoom | 4x |
| Aantal lenzen | 1 |
| Brandpuntbereik | 4.8 - 120.5 mm |
| Dichtstbijzijnde focus afstand | 1,5 m |
| Video | |
| Maximum resolutie | 3840 x 2160 Pixels |
| Totaal aantal megapixels | 8,5 MP |
| Ondersteunde videoformaten | H.264, H.265 |
| Ondersteunde video-modi | 480p, 720p, 1080p, 3840p |
| Maximaal 30 frames per seconde | 59,94 fps |
| Videostreaming | Ja |
| Audio | |
| Ondersteund audioformaat | AAC |
| Netwerk | |
| Ethernet LAN | Ja |
| Netwerkstandaard | IEEE 802.3af |
| Methode voor streaming | Multicast |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| RS-232 port | 1 |
| Aantal HDMI-poorten | 1 |
| Aansluiting voor netstroomadapter | Ja |
| Energie | |
| Type stroombron | DC, Power over Ethernet (PoE) |
| Stroomuitvoer (volt) | 12 |
| Gewicht en omvang | |
| Breedte | 70,9 mm |
| Diepte | 178,3 mm |
| Hoogte | 80,1 mm |
| Gewicht | 872 g |
| Inhoud van de verpakking | |
| Aantal cameras | 1 |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85258900 |
| Warranty | |
| Base Warranty | Non Non |
