Product Informatie
Mellanox MCX653105A-ECAT-SP (Single Pack MCX653105A-ECAT available through distribution.) ConnectX-6 VPI Adapter Card HDR100 EDR IB and 100GbE Single-Port QSFP56 PCIe3.0/4.0 x16 Tall Bracket.
World's first 200Gb/s HDR InfiniBand and Ethernet network adapter card, offering industry-leading performance, smart offloads and In-Network Computing, leading to the highest return on investment for High-Performance Computing, Cloud, Web 2.0, Storage and Machine Learning applications.
ConnectX-Virtual Protocol Interconnect (VPI) is a groundbreaking addition to the Mellanox ConnectX series of industry-leading adapter cards. Providing two ports of 200Gb/s for InfiniBand and Ethernet connectivity, sub-600ns latency and 215 million messages per second, ConnectX-6 VPI enables the highest performance and most flexible solution aimed at meeting the continually growing demands of data center applications.
In addition to all the existing innovative features of past versions, ConnectX-6 offers a number of enhancements to further improve performance and scalability.
ConnectX-6 VPI supports HDR, HDR100, EDR, FDR, QDR, DDR and SDR InfiniBand speeds as well as 200, 100, 50, 40, 25, and 10Gb/s Ethernet speeds.
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| Hostinterface | PCI Express |
| Interface | Ethernet / Fiber |
| Fibre channel-poorten | 1 |
| Vezel-optische connector | QSFP56 |
| PCI versie | 4.0 |
| Netwerk | |
| Maximale overdrachtssnelheid van gegevens | 100000 Mbit/s |
| Netwerkstandaard | IEEE 1588, IEEE 802.1Q, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3ba |
| Ethernet LAN | Ja |
| Ethernet interface type | 10 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, Gigabit Ethernet |
| Ethernet LAN, data-overdrachtsnelheden | 10000,25000,40000,50000,100000 Mbit/s |
| Design | |
| Component voor | Server |
| Kleur van het product | Meerkleurig |
| Intern | Ja |
| Technische details | |
| Certificaten van naleving | RoHS |
| Warranty | |
| Base Warranty | Non Non |
