Aruba AP-503HR (EU) Remote AP bundle with AP-503H (RW) + desk mount + power adapter + EU power cord
ITCurry #: 1171YW53 | Article #: R7G96A-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
HPE Aruba Networking 500H Series Hospitality Access Points deliver cost-effective Wi-Fi 6 coverage in a compact form factor that is ideal for hotels, residence halls, and remote offices. With 1.49 Gbps maximum combined speed, zero touch provisioning (ZTP), and wired ports, the 500H series is ready to improve wireless experiences for guests, employees, students, and teleworkers. The 500H series is Wi-Fi CERTIFIED and supports 802.11ax features; orthogonal frequency-division multiple access (OFDMA) for multi-user efficiency, target wake time (TWT) to extend the battery life of connected Internet of Things (IoT) devices, and WPA3 and Enhanced Open (OWE) for greater password and guest security. The 500H series includes a limited lifetime warranty.
What is new supporting point:
Zero touch provisioning (ZTP) provides ease of implementation in branch offices and remote sites, without on-site technical expertise
Dynamic segmentation and policy enforcement firewalls (PEFs) automatically enforce consistent policies across the network, enhancing user and device security
The AP provides IoT-ready Bluetooth 5 and Zigbee support
The AP provides supports for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security
Cost-effective Wi-Fi 6 hospitality access points provide up to 1.49 Gbps maximum combined data rate with a range of connectivity options for venues such as hotels, residence halls, and remote offices
You can customize deployment with optional desktop stand and models that offer choice of wired connectivity, USB, and PoE out support
| Kenmerken | |
| 2,4 GHz | Ja |
| 5 GHz | Ja |
| Maximale overdrachtssnelheid van gegevens | 1487 Mbit/s |
| Maximale overdrachtssnelheid van gegevens (2.4 GHz) | 287 Mbit/s |
| Maximale overdrachtssnelheid van gegevens (5 GHz) | 1200 Mbit/s |
| Ethernet LAN, data-overdrachtsnelheden | 10,100,1000 Mbit/s |
| Netwerkstandaard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3az |
| Bluetooth | Ja |
| Bluetooth-versie | 5.0 |
| Auto MDI/MDI-X | Ja |
| MIMO | Ja |
| MIMO-type | Multi User MIMO |
| Spread spectrum methode | DSSS, OFDM, OFDMA |
| Modulatie | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
| Beveiliging | |
| Ondersteunde beveiligingsalgoritmen | WPA2, WPA3 |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten | 2 |
| USB-connectortype | Micro-USB B |
| Energie | |
| Power over Ethernet (PoE) | Ja |
| Stroomverbruik (typisch) | 10 W |
| Design | |
| Plaatsing | Tafel, Muur |
| Kleur van het product | Wit |
| Antenne | |
| Soort antenne | Intern |
| Type antennerichting | Semi-directioneel |
| Antennefuncties | Ingebouwde antenne |
| Antennas quantity | 2 |
| Antenne versterkingsniveau (max) | 5,6 dBi |
| Certificaten | |
| Certificaten van naleving | Federal Communications Commission (FCC), ISED, CE, Elektromagnetische compatibiliteit (EMC), Laagspanningsrichtlijn (LVD) |
| Certificering | None |
| Gewicht en omvang | |
| Breedte | 86 mm |
| Diepte | 47 mm |
| Hoogte | 150 mm |
| Gewicht | 360 g |
| Eisen aan de omgeving | |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 93 procent |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Luchtvochtigheid bij opslag | 5 - 93 procent |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
