Aruba AP-203R RW Unified Remote Access Point
ITCurry #: 1171XA82 | Article #: JY712A-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
This compact, cost-effective remote access point is software configurable to operate in either 1x1 dual radio mode, or 2x2 single radio mode.
Managed by the Aruba Mobility Controller, the 203R supports centralized configuration, data encryption, policy enforcement and network services. It extends corporate resources to remote locations by establishing site-to-site VPN tunnels to the data center.
It offers a variety of enterprise-class features which gives remote workers the same high-quality Wi-Fi experience they get at corporate headquarters.
Get a big performance advantage
Patented ClientMatch™ technology improves performance and eliminates sticky client behavior while roaming.
Protect service quality over the air
AppRF technology enables prioritization and policy enforcement for business-critical enterprise apps like Microsoft Lync.
You have the freedom to choose
The RAP-203R can be deployed as a wall-mounted hospitality AP or converted to a desk mounted remote AP.
| Kenmerken | |
| 2,4 GHz | Ja |
| 5 GHz | Ja |
| Maximale overdrachtssnelheid van gegevens | 1000 Mbit/s |
| Maximale overdrachtssnelheid van gegevens (5 GHz) | 867 Mbit/s |
| Ethernet LAN, data-overdrachtsnelheden | 10,100,1000 Mbit/s |
| Netwerkstandaard | IEEE 802.11ac |
| Auto MDI/MDI-X | Ja |
| Spread spectrum methode | DSSS, OFDM |
| Modulatie | 16-QAM, 64-QAM, 256-QAM, BPSK, QPSK |
| Zendvermogen | 21 dBmW |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten | 2 |
| Aantal USB 2.0-poorten | 1 |
| USB-connectortype | USB Type-A |
| WAN-poort | Ethernet (RJ-45) |
| Aansluiting voor netstroomadapter | Ja |
| Energie | |
| AC-ingangsspanning | 90 - 265 V |
| AC-ingangsfrequentie | 47-63 Hz |
| Vermogensverbruik (max) | 7,5 W |
| Design | |
| Plaatsing | Tafel, Muur |
| Kleur van het product | Wit |
| Reset button | Ja |
| LED-indicatoren | Stroom, Status |
| Certificering | CB Scheme Safety, cTUVus |
| Intern | Nee |
| Antenne | |
| Antennefuncties | Ingebouwde antenne |
| Antennas quantity | 2 |
| Gewicht en omvang | |
| Breedte | 155 mm |
| Diepte | 50 mm |
| Hoogte | 95 mm |
| Gewicht | 320 g |
| Verpakking | |
| Breedte verpakking | 224 mm |
| Diepte verpakking | 159 mm |
| Hoogte verpakking | 78 mm |
| Gewicht verpakking | 510 g |
| Inhoud van de verpakking | |
| Snelstartgids | Ja |
| Eisen aan de omgeving | |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 93 procent |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
