Touchcomputer 22c2 22-inch Dual Touch Fanless
ITCurry #: M0133021 | Article #: E335320-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The Elo TouchSystems CM-Series All-in-One touchcomputers for healthcare applications platform leverages the same quality, performance, configurations and design as our popular C-Series touchcomputer. The CM-Series offers bigger, brighter displays in a wide-aspect ratio. This makes the CM-Series an excellent choice for applications requiring a larger display area than traditional touch computers. Particularly desirable for viewing images, including patient characteristics, training and education where high quality visual presentation is required.
The CM-Series touchcomputers bring flexibility with a choice of configuration and connectivity, serviceability with easy access to key components, and a choice in processing power. In addition, an array of field-installable peripherals, spill-resistant sealing, and a selection of input/output port connection options make the CM-Series both versatile and powerful. It is designed with the future in mind, allowing easy field serviceability of all of the main components.
The CM-Series is engineered for flexibility, with optional memory and storage configurations, as well as scalable computing power featuring two high-performance processor configurations:
- Cool and Quiet CM2 Fan-less Intel Atom Dual-Core 1.66 GHz
- Performance Ultra CM3 Fan-cooled Intel Core 2 Duo 3.0 GHz
The flexibility, serviceability and performance of the CM-Series are rare in all-in-one touchcomputers designed for healthcare applications. In a stylish, compact design, the CM-Series provides highly configurable, ruggedized touchcomputers, in two screen sizes: 19-inch and 22-inch, plus the choice of industry-leading TE touchscreen technologies: AccuTouch 5-wire resistive, IntelliTouch surface acoustic wave and iTouch zero-bezel surface acoustic wave. The CM-Series touchcomputer family has been developed to meet the demanding needs of healthcare applications and is ready to be deployed with confidence in any healthcare facility requiring additional security offered by medical certifications.
All these models also support multiple customer-installable memory and storage configurations including:
- Up to 4GB1 RAM
- 2nd hard drive option, for expanded storage or RAID configuration
- A full-range of standard connectivity ports including:
- 6 x standard USB 2.0
- 2 x USB-to-Serial RS-232
- 1 x Gigabit Ethernet
- 3 x 3.5mm audio (line in, mic in, audio out)
- HDMI out (C3 only)
Elo CM-Series touchcomputers are offered with your choice of the following operating systems (OS): Windows 7, or no OS. Models with the IntelliTouch Plus product technology and Windows 7 support multi-touch functionality. Other touch product technologies with Windows 7 Operating System support single-finger gestures only.
| Beeldscherm | |
| Beeldschermdiagonaal | 54,6 cm (21.5") |
| Resolutie | 1920 x 1080 Pixels |
| Touchscreen | Ja |
| HD type | Full HD |
| Oorspronkelijke beeldverhouding | 16:9 |
| Helderheid | 225 cd/mý |
| Typische contrastverhouding | 1000:1 |
| Kijkhoek, horizontaal | 170ø |
| Kijkhoek, verticaal | 160ø |
| Beeldscherm, aantal kleuren | 16.78 miljoen kleuren |
| Processor | |
| Processorfabrikant | Intel |
| Processormodel | D510 |
| Processorfamilie | Intel Atom© |
| Frequentie van processor | 1,66 GHz |
| Aantal processorkernen | 2 |
| Processor aantal threads | 4 |
| Processor cache | 1 MB |
| Processor cache type | L2 |
| Thermal Design Power (TDP) | 13 W |
| Front-side bus processor | 533 MHz |
| Processor socket | BGA 559 |
| Processor lithografie | 45 nm |
| Processor operating modes | 64-bit |
| Stepping | B0 |
| Bus type | DMI |
| Codenaam processor | Pineview |
| Processorserie | Intel Atom D500 Series |
| FSB Parity | Nee |
| Processorcode | SLBLA |
| Tjunction | 100 øC |
| Aantal Processing Die Transistors | 176 M |
| Processing die grootte | 87 mmý |
| Maximaal intern geheugen ondersteund door processor | 4 GB |
| Conflictvrije processor | Nee |
| Geheugentypen ondersteund door processor | DDR2 667/800 |
| Geheugenbandbreedte ondersteund door de processor ( max) | 6,4 GB/s |
| Geheugenkanalen ondersteund door processor | Enkel |
| ECC ondersteund door processor | Nee |
| Geheugen | |
| Intern geheugen | 2 GB |
| Intern geheugentype | DDR2-SDRAM |
| Maximum intern geheugen | 4 GB |
| Kloksnelheid geheugen | 800 MHz |
| Geheugenlayout | 1 x 2 GB |
| Opslagmedia | |
| Totale opslagcapaciteit | 160 GB |
| Het aantal ge‹nstalleerde HDD's | 1 |
| HDD capaciteit | 160 GB |
| HDD omvang | 2.5" |
| HDD interface | SATA |
| Soort optische drive | Nee |
| Ge‹ntegreerde geheugenkaartlezer | Nee |
| Grafisch | |
| Discreet grafische adapter model | Niet beschikbaar |
| Ingebouwde grafische adapter | Ja |
| Audio | |
| Aantal luidsprekers | 2 |
| Netwerk | |
| Wifi | Nee |
| Ethernet LAN | Ja |
| Ethernet LAN, data-overdrachtsnelheden | 10,100,1000 Mbit/s |
| Poorten & interfaces | |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Aantal USB 2.0-poorten | 6 |
| VGA (D-Sub)poort(en) | 1 |
| DVI-poort | Nee |
| Hoofdtelefoonuitgangen | 1 |
| Microfoon, line-in ingang | Ja |
| Seri‰le poort(en) | 2 |
| Design | |
| Kleur van het product | Wit |
| Bevestigingsmogelijkheid voor kabelslot | Ja |
| Kabelslot sleuf type | Kensington |
| Software | |
| Architectuur besturingssysteem | 32-bit |
| Inclusief besturingssysteem | Windows 7 Professional |
| Processor speciale functies | |
| Intel© Turbo Boost Technology | Nee |
| Intel© Hyper Threading Technology (Intel© HT Technology) | Ja |
| Intel© My WiFi Technology (Intel© MWT) | Nee |
| Intel© Anti-Theft Technology (Intel© AT) | Nee |
| Intel© Wireless Display (Intel© WiDi) | Nee |
| Enhanced Intel SpeedStep Technology | Nee |
| Intel© Quick Sync Video Technology | Nee |
| Intel© Clear Video HD Technology (Intel© CVT HD) | Nee |
| Intel© Clear Video-technologie | Nee |
| Intel© InsiderT | Nee |
| Intel© InTruT 3D Technology | Nee |
| Intel© Flex Memory Access | Nee |
| Intel© AES New Instructions (Intel© AES-NI) | Nee |
| Intel© Trusted Execution Technology | Nee |
| Intel© Enhanced Halt State | Nee |
| Intel© VT-x with Extended Page Tables (EPT) | Nee |
| Intel© Demand Based Switching | Nee |
| Intel© Clear Video Technology for Mobile Internet Devices (Intel© CVT for MID) | Nee |
| Intel© 64 | Ja |
| Execute Disable Bit | Ja |
| Idle States | Nee |
| Thermal Monitoring Technologies | Nee |
| Verpakkingsgrootte processor | 22 x 22 mm |
| Ondersteunde instructie sets | SSE2, SSE3, SSSE3 |
| Physical Address Extension (PAE) | 32 Bit |
| Ingebouwde opties beschikbaar | Ja |
| Intel© Virtualization Technology for Directed I/O (VT-d) | Nee |
| Intel© Virtualization Technology (VT-x) | Nee |
| Intel© Dual Display Capable Technology | Nee |
| Intel© FDI Technology | Nee |
| Intel© Rapid Storage Technology | Nee |
| Intel© Fast Memory Access | Nee |
| ARK ID processor | 43098 |
| Energie | |
| AC-adapterfrequentie | 50/60 Hz |
| AC-adapter ingangsspanning | 100 - 240 V |
| Stroomverbruik (typisch) | 54 W |
| Gewicht en omvang | |
| Breedte apparaat (met standaard) | 540 mm |
| Diepte apparaat (met standaard) | 98 mm |
| Hoogte apparaat (met standaard) | 333 mm |
| Gewicht (met standaard) | 8,3 kg |
| Gewicht verpakking | 14,9 kg |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 35 øC |
| Temperatuur bij opslag | -30 - 60 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 20 - 80 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Certificaten | |
| Certificering | UL 60601-1, cUL (CAN/CSA-C22.2 No. 601.1-M90), TUV (EN 60601-1), CB (IEC 60601-1), IPX1, FCC (A), CE (A), VCCI (A), C-Tick (A), NOM COC, AR S-Mark, GOST-R, WEEE, CE |
| Overige specificaties | |
| Grafische adapter-familie | Intel |
| Afmetingen verpakking (BxDxH) | 600 x 360 x 516 mm |
| Bekabelingstechnologie | 10/100/1000Base-T(X) |
| Type behuizing | Alles-in-een |
| Voldoet aan industriestandaarden | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Beeldscherm | TFT LCD |
| Inclusief monitor | Ja |
| Lijningang | Ja |
| Mac-compatibiliteit | Nee |
| Netwerkfuncties | Gigabit Ethernet |
| Aantal ge‹nstalleerde processoren | 1 |
| Bedrijfstemperatuur, bereik | 32 - 95 øF |
| Platform | PC |
| Netvoeding | 180 W |
| Soort voeding | AC |
| Luidsprekers | monitor built-in |
| Warranty | |
| Base Warranty | Non Non |
