TRIPP LITE Smartpro Medical Grade 0.7kva 230v Line Interactive Tower UPS Full Isolation USB & Serial Ports
ITCurry #: 57903643 | Article #: SMX700HG
Verwante producten
Product Informatie
The SMX700HG medical-grade UPS system provides dependable battery backup and is fully compliant with UL 60601-1 regulations when plugged into a hospital-grade outlet, making it ideal for use in patient care vicinities. The 700VA/450W capacity provides up to 36 minutes of runtime for a half load or 14.5 minutes for a full load, so you can work through short power failures and perform an orderly system shutdown in a prolonged blackout.
Built-in line-interactive voltage regulation corrects brownouts as low as 155V and overvoltages as high as 274V to normal 230V nominal output, without drawing battery power. The SMX700HG’s built-in isolation transformer with Faraday shield offers full isolation and removes common mode noise while maintaining full AC surge suppression in all modes. Cumulative leakage current of all connected equipment is less than 100 microamps.
This UPS system features six IEC320 C13 hospital-grade outlets and has a hospital-grade IEC320 C14 plug on a 15-centimeter (six-inch) dongle. All six outlets provide both backup protection and surge protection, rated to 340 joules.
The SMX700HG also features diagnostic LEDs, as well as a USB port and a DB9 serial port that work with free downloadable PowerAlert® software for safe, unattended system shutdown in the event of a prolonged power failure.
This UPS contains a lead acid battery designed to be connected continuously to an AC power source, except during brief power outages. It is not intended for frequent charge/discharge cycles, such as mobile cart applications where the UPS is often disconnected from the power source. Using the SMX700HG in this type of application will void the battery warranty.
| Warranty | |
| Base Warranty | Non Non |
| Kenmerken | |
| Output power capacity | 0,7 kVA |
| Uitgangsvermogen | 450 W |
| Ingang operation voltage (min) | 220 V |
| Ingang operation voltage (max) | 240 V |
| Frequentie | 50/60 Hz |
| Uitgang operation voltage (min) | 230 V |
| Uitgang operation voltage (max) | 230 V |
| Stroom (max.) | 3,6 A |
| Surge energy rating | 340 J |
| Responstijd | 5 ms |
| EMI/RFI geluidsfiltering | Ja |
| Geluidsalarm(en) | Ja |
| Land van herkomst | China |
| Poorten & interfaces | |
| Stopcontacttypes | C13 stekker |
| Stekker | C14 stekker |
| Aantal AC uitgangen | 6 AC-uitgang(en) |
| Aantal USB 2.0-poorten | 1 |
| RS-232 port | 1 |
| Accu/Batterij | |
| Typische backup tijd op volledige lading | 14,5 min |
| Typische backup tijd op halve lading | 36 min |
| Accu/Batterij oplaadtijd | 3,6 uur |
| Hot-swap batterij | Ja |
| Koude start | Ja |
| Design | |
| Vormfactor | Tower |
| Materiaal behuizing | Polyvinyl chloride (PVC) |
| Snoerlengte | 1,83 m |
| Type koeling | Actief |
| Kleur van het product | Wit |
| LED-indicatoren | Ja |
| Certificering | CE/IEC 60601-1, FCC B |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -15 - 50 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 95 procent |
| Technische details | |
| Certificaten van naleving | RoHS |
| Gewicht en omvang | |
| Breedte | 190,5 mm |
| Diepte | 229 mm |
| Hoogte | 325 mm |
| Gewicht | 19,1 kg |
| Breedte verpakking | 309,9 mm |
| Diepte verpakking | 339,9 mm |
| Hoogte verpakking | 469,9 mm |
| Gewicht verpakking | 20,6 kg |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85078000 |
| Hoeveelheid per (buitenste) hoofdverpakking | 1 stuk(s) |
| Overige specificaties | |
| Nominale input voltage | 230 V |
| Afmetingen verpakking (BxDxH) | 310 x 340 x 470 mm |
