UPS External Battery Pack for 6kVA and 10kVA UPS Models (Extended Pack)
ITCurry #: M9238700 | Article #: DN-170108-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
A solution that increases the operating capacity of intelligent USV systems to protect IT devices with medium to high loads
- Rack / tower with convertible design
- Hot swappable – Batteries can be exchanged during operation
- Supports rapid extension of backup time in case of increased need for capacity
- Easy installation – Batteries can be exchanged by the user
- Supports cold start function
The DIGITUS® USV Battery Modules ensure that UPS systems used in highly demanding environments can continue to reliably supply connected devices with power in case of interruptions to the power supply. A maximum of 4 battery modules can be connected in order to increase the operating time of the connected IT devices. The systems are protected by ensuring uninterrupted power supply while changing the batteries. The external battery backs can ensure a rapid increase for the bridging period in case of increasing need.
| Design | |
| Vormfactor | Rackmontage/toren |
| UPS-topologie | Dubbele conversie (online) |
| Rack-montage | Ja |
| Rackcapaciteit | 2U |
| Kleur van het product | Zwart |
| Materiaal behuizing | Metaal |
| Accu/Batterij | |
| Ondersteund aantal accu's/batterijen | 20 |
| Accu/Batterij voltage | 120 V |
| Hot-swap batterij | Ja |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 20 - 25 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 90 procent |
| Gewicht en omvang | |
| Breedte | 443 mm |
| Diepte | 680 mm |
| Hoogte | 131 mm |
| Gewicht | 65 kg |
| Breedte verpakking | 585 mm |
| Diepte verpakking | 730 mm |
| Gewicht verpakking | 68,2 kg |
| Inhoud van de verpakking | |
| Aantal | 1 |
| Technische details | |
| Verpakkingsvolume | 119574 cmü |
| Logistieke gegevens | |
| Code UK-handelstarief | 85044085 |
| Land van herkomst | China |
| Warranty | |
| Base Warranty | Non Non |
