network rack, 22U Dynamic Basic 1155x600x600mm, black (RAL 9005)
ITCurry #: M9238574 | Article #: DN-19 22U-6/6-DB-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The DIGITUS® Dynamic Basic Series is made for high demand IT-Infrastructure Solutions - designed and developed on highest standard in Germany
- Roof is prepared for fan units (punched out entries)
- Lockable pivot lever on front door
- Base with punched out cable entry, covered with screwed metal plate
The network cabinets from the Dynamic series were developed for easy and especially cost-optimized network expansion. Clever placement of the cable inlets ensures effortless installation for every application. They are located at the back center in the floor structure, protected by a bolted cover plate. Cabinets from a width of 800 mm also feature cable inlets with a plastic cover to the left and right. These are also integrated into the roof (1 x for 600 mm cabinet width, 3 x for 800 mm cabinet width). To accommodate a fan module, the roof structure is also equipped with a pre-cut area. Two pairs of galvanized 483 mm (19”) profile rails labeled with rack units readable in both directions are installed on the inside. Their depth is adjustable and they are connected to additional depth bars in the cabinet. Each cabinet is made of up to 1.5 mm thick sheet steel. Coloring is done with electrostatic powder coating in the standard colors gray (RAL 7035) or jet black (RAL 9005). Removable side and back walls as well as lockable and removable front door improve accessibility. The door hinges can be switched. Furthermore, the cabinets can be completely dismantled if necessary due to their collapsible design.
| Kenmerken | |
| Rackcapaciteit | 22U |
| Soort | Vrijstaande rek |
| Maximale gewichtscapaciteit | 600 kg |
| Kleur van het product | Zwart |
| Materiaal | Gegalvaniseerd staal |
| Achterdeurconstructie | Staal |
| Voordeurconstructie | Glas |
| Zijpaneelconstructie | Staal |
| Afneembare achterdeur | Ja |
| Verwijderbare zijpanelen | Ja |
| Inbegrepen zijpanelen | Ja |
| Sleutelsleuf | Ja |
| Sleutelvergrendeling achterdeur | Ja |
| Voordeur met sleutelvergrendeling | Ja |
| Zijpaneel met sleutelvergrendeling | Ja |
| Rekrails | Ja |
| Rekrail dikte | 48,3 cm |
| Verstelbare voeten | Ja |
| Type koeling | Passief |
| Internationale veiligheidscode (IP) | IP20 |
| Gewicht en omvang | |
| Breedte | 600 mm |
| Diepte | 600 mm |
| Hoogte | 1164 mm |
| Gewicht | 38 kg |
| Verpakking | |
| Breedte verpakking | 650 mm |
| Diepte verpakking | 650 mm |
| Hoogte verpakking | 1175 mm |
| Verpakkingsvolume | 509112 cmü |
| Gewicht verpakking | 39 kg |
| Logistieke gegevens | |
| Code UK-handelstarief | 94032080 |
| Land van herkomst | Turkije |
| Code geharmoniseerd systeem (HS) | 85381000 |
| (Buitenste) hoofdverpakking breedte | 650 mm |
| (Buitenste) hoofdverpakking lengte | 650 mm |
| (Buitenste) hoofdverpakking hoogte | 1175 mm |
| (Buitenste) hoofdverpakking brutogewicht | 39 kg |
| (Buitenste) hoofdverpakking inhoud | 496438 cmü |
| Hoeveelheid per (buitenste) hoofdverpakking | 1 stuk(s) |
| Warranty | |
| Base Warranty | Non Non |
