Media Converter, Multimode 10/100Base-TX to 100Base-FX, Incl. PSU ST connector, Up to 2km
ITCurry #: M9236303 | Article #: DN-82010-1
Verwante producten
Product Informatie
The perfect converter solution for various fiber media
- Transmits data in high quality and additionally provides excellent reliability
- Long range up to 2km by the multimode fiber dual
- Automatic cable detection
The Media Converters from DIGITUS are the ideal solution for the migration of Copper and Fiber Network Signals. From now on, you are able to access the Fiber Technology and transfer network signals over several kilometers without renewing your whole Network Infrastructure. The huge variety of Products fulfil your individual needs. The intiutive operation guarantees a quick and easy Installation. The Link Fault Pass Through function offers a no-fear-networking. Your Network Administrator will be able to find and solve Network problems easily. Years of Experience and a wide range of products lets DIGITUS become a reliable Partner for your Network.
| Netwerk | |
| Converter input interface | 100Base-TX |
| Converter output interface | 100Base-FX |
| Netwerkstandaard | IEEE 802.3, IEEE 802.3u |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN, data-overdrachtsnelheden | 10,100 Mbit/s |
| Auto MDI/MDI-X | Ja |
| Duplex systeem | Volledig, Half |
| Prestatie | |
| Maximaal bereik | 2000 m |
| Golflengte | 1310 nm |
| Draad modus structuur | Multimode |
| Vezelkabel diameters ondersteund | 50/125,62.5/125 æm |
| Tx vermogen (min) | -22 dBmW |
| Tx vermogen (max) | -12 dBmW |
| Rx vermogen (min) | -30 dBmW |
| Buffergrootte | 128 KB |
| Kenmerken | |
| Intern | Ja |
| LED-indicatoren | Activiteit, Link, Stroom |
| Kleur van het product | Zwart |
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Fibre channel-poorten | 1 |
| Vezel-optische connector | ST |
| Aansluiting voor netstroomadapter | Ja |
| Energie | |
| Ingangsspanning | 5 V |
| Stroomverbruik (typisch) | 2,5 W |
| Power over Ethernet (PoE) | Nee |
| Externe adapter | Ja |
| Gewicht en omvang | |
| Gewicht | 200 g |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 55 øC |
| Inhoud van de verpakking | |
| Gebruiksaanwijzing | Ja |
| Verpakking | |
| Breedte verpakking | 216 mm |
| Diepte verpakking | 60 mm |
| Verpakkingsvolume | 2086,56 cmü |
| Gewicht verpakking | 500 g |
| Logistieke gegevens | |
| Land van herkomst | China |
| Code UK-handelstarief | 85176200 |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Overige specificaties | |
| Afmetingen (B x D x H) | 95 x 70 x 26 mm |
| Transmissie afstand (max) | 2 km |
| Warranty | |
| Base Warranty | Non Non |
