Cisco Nexus 3524-xl 24 Sfp+ Ports Enhanced Extended Memory
ITCurry #: 0918P925 | Article #: N3K-C3524P-XL-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
High Performance with Flexible Deployments
The Cisco Nexus 3524 Switch, part of the Unified Fabric Family, is well suited for mainstream top-of-rack (TOR) data center deployments. It offers wire-rate Layer 2 and Layer 3 switching with a comprehensive feature set, including Algo Boost technology, and ultra-low latency. All comes in a compact, cost effective, 1-rack-unit (1RU) form factor.
Features and Capabilities
Algo Boost technology allows the Cisco Nexus 3524 to achieve exceptionally low latencies of 250 nanoseconds (ns) or less for all workloads. That includes unicast and multicast, and Layer 2 and 3, regardless of the features applied.
Among other benefits:
- Warp mode can further reduce latency to 190 ns for small-to-midsize Layer 2 and 3 deployments.
- Warp SPAN helps enables stock market data delivery to trading servers in as little as 50 ns.
- Active Buffer Monitoring helps you take advantage of market volatility and handle micro bursts.
- Technology supports Network Address Translation (NAT) for trade execution on any venue, without a latency penalty.
- Embedded Remote SPAN with nanosecond timestamps helps you monitor your traffic with unparalleled precision.
Comprehensive Feature Set with Cisco NX-OS
The Cisco Nexus 3524 is powered by the data-center-class Cisco NX-OS operating system. Features include:
- Full-featured unicast protocols including BGP, OSPF, EIGRP, and RIP
- Multicast protocols include PIM-SM, PIM-SSM, and MSDP
- Full support for access control lists (ACLs; port, VLAN, and routed) and quality of service (QoS; queueing and marking)
- Full support for troubleshooting tools such as Switched Port Analyzer (SPAN) and Ethanalyzer
- Switch management by Cisco Prime Data Center Network Manager (DCNM)
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L2/L3 |
| Quality of Service (QoS) | Ja |
| Web-gebaseerd management | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 24 |
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
| Aantal Gigabit Ethernet (koper)-poorten | 2 |
| Aantal moduleslots SPF+ | 24 |
| Console port | RS-232 |
| Aantal USB 2.0-poorten | 2 |
| Netwerk | |
| Netwerkstandaard | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3z |
| 10G support | Ja |
| IP routing | Ja |
| Verbindingsaggregatie | Ja |
| Spanning tree protocol | Ja |
| VLAN=ondersteuning | Ja |
| Virtuele LAN-functies | Private VLAN, Tagged VLAN |
| Aantal VLANs | 4096 |
| Data-uitwisseling | |
| Switchingcapaciteit | 480 Gbit/s |
| Throughput | 360 Mpps |
| MAC-adrestabel | 64000 entries |
| Jumbo Frames ondersteuning | Ja |
| Jumbo frames | 9216 |
| Packet buffergeheugen | 18 MB |
| Beveiliging | |
| Access Control List (ACL) | Ja |
| Multicast-functies | |
| Multicast-ondersteuning | Ja |
| Protocollen | |
| Beheerprotocollen | SSHv2, SNMP v1/v2/v3, RADIUS, TACACS+ |
| Ondersteunde netwerkprotocollen | IPv4, IPv6 |
| Design | |
| Rack-montage | Ja |
| Vormfactor | 1U |
| Kleur van het product | Grijs |
| Prestatie | |
| Flash memory | 2048 MB |
| Mean time between failures (MTBF) | 317030 uur |
| Energie | |
| Aantal voedingen | 2 |
| AC-ingangsspanning | 100 - 240 V |
| Stroomverbruik (typisch) | 102 W |
| Vermogensverbruik (max) | 193 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Nee |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 85 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Hoogte, in bedrijf | 0 - 3000 m |
| Warmtedissipatie | 904 BTU/h |
| Gewicht en omvang | |
| Breedte | 439 mm |
| Diepte | 467 mm |
| Hoogte | 43,6 mm |
| Gewicht | 7,9 kg |
| Warranty | |
| Base Warranty | Non Non |
