Cisco Catalyst 2960c Switch 8 Fe Lan Lite 2x Dual Uplink / Refurb
ITCurry #: 0918AG93 | Article #: WS-C2960C-8TC-S-RF-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Catalyst 2960-C
Cisco® Catalyst® compact switches easily extend an intelligent, fully managed Cisco Catalyst wired switching infrastructure, including end-to-end IP and Borderless Network services, with a single Ethernet cable or fiber from the wiring closet. These attractive, small form-factor Fast Ethernet switches are ideal for connecting multiple devices on the retail sales floor; in classrooms, hotels, and factories; and for extending wireless LAN networks: wherever space is at a premium and multiple cable runs could be challenging.
Cisco Catalyst 2960-C Series Compact Switche highlights:
- Extend a highly secure, intelligent, managed Cisco Catalyst infrastructure with a single Ethernet cable or fiber from the wiring closet;
- Support for advanced security and services, including voice, video, and Cisco Borderless Network services, to remote endpoints;
- Attractive, small form factor and fanless operation fit in confined spaces where multiple cable runs could be challenging;
- Easy to deploy, manage and extend the network loop free;
- Enhanced limited lifetime hardware warranty.
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L2 |
| Quality of Service (QoS) | Ja |
| Web-gebaseerd management | Ja |
| Traffic-classificatie | Ja |
| ARP-inspectie | Ja |
| System event log | Ja |
| MIB-ondersteuning | RMON-MIB, RMON2-MIB, Bridge-MIB, CDP-MIB, Entity-MIB, ENVMON-MIB, Flash-MIB, FTP-MIB, Image-MIB, IP-Stat-MIB, LAG-MIB, MAC-MIB, PAGP-MIB, Ping-MIB, QOS-MIB, Security-MIB, RTTMON-MIB, SMI-MIB, STP-MIB, Syslog-MIB, TC-MIB, TCP-MIB, UDLDP-MIB, VTP-MIB, Eth-MIB, PAE-MIB, IF-MIB, IP-MIB, TS-MIB, UDP-MIB, ePM MIB |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 8 |
| Type basis-switching RJ-45 Ethernet-poorten | Fast Ethernet (10/100) |
| Aantal Gigabit Ethernet (koper)-poorten | 2 |
| Aantal Combo SFP-poorten | 2 |
| Fibre channel-poorten | 2 |
| Console port | RS-232 |
| Aantal USB 2.0-poorten | 2 |
| Netwerk | |
| Netwerkstandaard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Nee |
| Koperen ethernetbekabelingstechnologie | 10BASE-T, 100BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-TX |
| Full duplex | Ja |
| IP routing | Ja |
| Routing entries | 4000 |
| Datastroombeheer | Ja |
| Verbindingsaggregatie | Ja |
| Broadcast stormbeheer | Ja |
| Rate limiting | Ja |
| Auto MDI/MDI-X | Ja |
| Spanning tree protocol | Ja |
| Aantal VLANs | 255 |
| Optische vezel | |
| Fiber ethernet cabling technologie | 100BASE-BX, 100BASE-FX, 100BASE-LX, 1000BASE-LH, 1000BASE-LX, 1000BASE-SX, 1000BASE-ZX |
| Data-uitwisseling | |
| Throughput | 3,8 Mpps |
| MAC-adrestabel | 8000 entries |
| Jumbo Frames ondersteuning | Ja |
| Beveiliging | |
| DHCP-functies | DHCP server |
| Access Control List (ACL) | Ja |
| IGMP snooping | Ja |
| Ondersteunde beveiligingsalgoritmen | 802.1x RADIUS, SSH |
| Statische poort beveiliging | Ja |
| SSH/SSL support | Ja |
| BPDU filtering / bescherming | Ja |
| Multicast-functies | |
| Multicast-ondersteuning | Ja |
| Protocollen | |
| Beheerprotocollen | SNMPv1/v2c/v3, LLDP, IGMP |
| Ondersteunde netwerkprotocollen | IP, IPv6, FTP, TFTP, UDP, ICMP, TCP, ARP, NTP, OSPFv2, BOOTP, Telnet |
| Design | |
| Rack-montage | Nee |
| Stapelbaar | Nee |
| Kleur van het product | Wit |
| LED-indicatoren | LAN, Link, Stroom, Ja |
| Veiligheid | UL, CAN/CSA, EN, IEC, CE, GB |
| Prestatie | |
| Intern geheugen | 128 MB |
| Flash memory | 64 MB |
| Mean time between failures (MTBF) | 516980 uur |
| Energie | |
| AC-ingangsspanning | 100 - 240 V |
| Stroom | 0.21 - 0.1 A |
| Stroomverbruik (typisch) | 11 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Nee |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -5 - 45 øC |
| Temperatuur bij opslag | -25 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 95 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Hoogte, in bedrijf | 0 - 3048 m |
| Hoogte bij opslag | 0 - 4000 m |
| Warmtedissipatie | 38 BTU/h |
| Gewicht en omvang | |
| Breedte | 269 mm |
| Diepte | 213 mm |
| Hoogte | 44,4 mm |
| Gewicht | 1,27 kg |
| Certificaten | |
| Certificering | FCC, EN, CE, AS/NZS, VCCI, KCC, ANATEL, CCC, GOST, ROHS, CLEI |
| Warranty | |
| Base Warranty | Non Non |
