Catalyst 9500 32-port 100g Only Essential
ITCurry #: 0918Q331 | Article #: C9500-32C-E-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The Cisco® Catalyst® 9500 Series Switches are the next generation of enterprise-class core and aggregation layer switches, supporting full programmability and serviceability. Based on an x86 CPU, the Catalyst 9500 Series is Cisco’s lead purpose-built fixed core and aggregation enterprise switching platform, built for security, IoT, and cloud. The switches come with a 4-core, 2.4-GHz CPU, 16-GB DDR4 memory, and 16-GB internal storage.
The Catalyst 9500 Series is the industry’s first purpose-built 40 Gigabit Ethernet line of switches targeted for the enterprise campus. These switches deliver unmatched table scale (MAC/route/ACL) and buffering for enterprise applications. The Catalyst 9500 Series includes nonblocking 40G Quad Small Form-factor Pluggable (QSFP+) and 1G/10G Small Form-factor Pluggable Plus (SFP/SFP+) switches with granular port densities that fit diverse campus needs. The switches support advanced routing and infrastructure services (such as Multiprotocol Label Switching [MPLS] Layer 2 and Layer 3 VPNs, Multicast VPN [MVPN], and Network Address Translation [NAT]); software-defined access border capabilities (such as a host tracking database, cross-domain connectivity, and VPN Routing and Forwarding [VRF]-aware Locator/ID Separation Protocol [LISP]); and network system virtualization with Cisco StackWise® virtual technology that are critical for their placement in the campus core. The platform also supports all the foundational high-availability capabilities such as patching, Graceful Insertion and Removal (GIR), Cisco Nonstop Forwarding with Stateful Switchover (NSF/SSO), redundant platinum-rated power supplies, and fans.
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L2/L3 |
| MIB-ondersteuning | Y |
| Poorten & interfaces | |
| Type basis-switching RJ-45 Ethernet-poorten | Nee |
| Aantal QSFP28-poorten | 32 |
| Netwerk | |
| Full duplex | Ja |
| VLAN=ondersteuning | Ja |
| Virtuele LAN-functies | Policy-based VLAN, Private VLAN |
| Aantal VLANs | 4000 |
| Optische vezel | |
| Type schakelende optische module | 100 Gigabit Ethernet |
| Data-uitwisseling | |
| Switchingcapaciteit | 64000 Gbit/s |
| MAC-adrestabel | 84000 entries |
| Jumbo Frames ondersteuning | Ja |
| Jumbo frames | 9216 |
| Beveiliging | |
| DHCP-functies | DHCP snooping |
| Access Control List (ACL) | Ja |
| IGMP snooping | Ja |
| Ondersteunde beveiligingsalgoritmen | 256-bit AES |
| MAC adres filtering | Ja |
| Multicast-functies | |
| Multicast-ondersteuning | Ja |
| Protocollen | |
| Beheerprotocollen | IGMP |
| Design | |
| Rack-montage | Ja |
| Kleur van het product | Grijs |
| Prestatie | |
| Type processor | Ja |
| Frequentie van processor | 2400 MHz |
| Type geheugen | DRAM |
| Intern geheugen | 16000 MB |
| Flash memory | 16000 MB |
| Energie | |
| Vermogenstoevoer inclusief | Ja |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -20 - 65 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 90 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
