Xd3-40d - Label Printer - Thermal - 118mm - Ethernet / USB/ Serial
ITCurry #: Q2922812 | Article #: XD3-40DEK/BEG-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The XD3-40d is a 4-inch (118mm) Direct Thermal Desktop Barcode and Label Printer featuring a compact design, key industry features and competitive pricing, ideal for labelling applications within Manufacturing, Retail, Warehousing and Logistics markets. The XD3-40d standard model offers quick data processing and print speeds up to 5 ips (127mm/sec) at 203 dpi to produce high quality text, graphics and barcodes to labelling media.
Supporting a stand-alone configuration with a visual LED and a media roll diameter up to 127mm. The XD3-40d offering easy paper loading with adjustable paper guide and plus holder, alongside an optional peeler, plus an external paper supply. For added simplicity, the label printer also offers simple toolless maintenance of the roller and print head.
Available with USB interface as standard and optional USB V2.0 + Serial + Ethernet. The XD3-40d is compatible with market-leading programming languages including SLCS, BPL-Z™ and BPL-E™, while supporting Smart Switch Programming Languages to allow for seamless integration into legacy and current installations. The XD3 series is also accompanied with comprehensive SDKs for Windows and Linux, alongside compatibility with label design software including BIXOLON’s Label Artist-II™ and BarTender®. While backed by a 2 year warranty as standard.
| Printsnelheid | |
| Printtechnologie | Direct thermisch |
| Printsnelheid (metrisch) | 127 mm/sec |
| Maximale print breedte | 10,4 cm |
| Minimale printlengte | 100 cm |
| Papier | |
| Lint-wijdte | 11 cm |
| Lint-lente | 300 m |
| Maximale label breedte | 11,8 cm |
| Maximum roll diameter | 12,7 cm |
| Mediadikte | 0.06 - 0.2 mm |
| Poorten & interfaces | |
| Connectiviteitstechnologie | Bedraad |
| USB-poort | Ja |
| Prestatie | |
| Paginabeschrijving talen | BPL |
| Intern geheugen | 64 MB |
| Flash memory | 128 MB |
| Ingebouwde streepjescodes | 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 39, EAN13, EAN8, GS1-128, Industrial 2/5, Interleaved 2/5, MaxiCode, MicroPDF417, QR Code, TLC39, UPC-A, UPC-E |
| Design | |
| Kleur van het product | Zwart |
| Energie | |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Minimale systeemeisen | |
| Ondersteunt Windows | Ja |
| Ondersteunt Linux | Ja |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -20 - 60 øC |
| Gewicht en omvang | |
| Breedte | 181 mm |
| Diepte | 222 mm |
| Hoogte | 168 mm |
| Gewicht | 1,7 kg |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 84433210 |
| Warranty | |
| Base Warranty | Non Non |
