Large Format Monitor - Pd-55q - 55in - 3840x2160 (uhd)
ITCurry #: 92942474 | Article #: PD-55Q
Verwante producten
Product Informatie
The PD-55Q 55-inch 4K commercial display features its 700 nits high brightness, suitable for use in different semi-outdoor environments, such as airport terminals, control rooms, and shopping malls. It integrates a full slate of input sources, including an embedded USB playback function, various I/O ports, and Intel® SDM slot. It allows you to broadcast multimedia content horizontally or vertically and it can meet different kinds of digital signage solutions as well as video wall installations.
700 nits High Brightness
The PD-55Q commercial display features 4K UHD, 10-bit colour depth, and 178-degree viewing angle for brilliant colour performance. Besides that, the display adopts a 700 nits brightness commercial-grade panel to deliver clear, bright, and detailed imagery even in the daylight or bright indoor environments.
IPS Panel for 24/7 Use
Designed for 24/7 operation, the PD-55Q display is produced to meet the highest standard of IPS panel technology and take advantage of superior components to ensure a long product lifetime in demanding environments.
Landscape/Portrait Capability
The commercial-grade signage-friendly and can perfectly fit either in a landscape or in a portrait mode to experience complete screen orientation flexibility and fulfill the need in different scenarios.
Optional Intel® SDM Capability
The built-in SDM slot is designed for Intel® smart display module, which is ready to create powerful smart signage for more user-friendly applications.
DisplayPort/IR/RS232 Daisy Chain Functionality
With DisplayPort daisy chain functionality, the video and audio can be delivered to multiple AG Neovo’s large format displays using DisplayPort cables, and it saves a significant amount of time. IR/RS232 loop-through capability provides a convenient single point of control for multi-display installation.
Embedded Image Enhancer
The embedded image enhancer features a 3D Comb Filter, 3D Deinterlace, and Noise Reduction to solve image issues – offering crystal clarity to the most demanding environments.
Integrated Content Scheduler
The built-in integrated scheduler in the OSD menu allows you to easily broadcast content based on source, time, and day by IR remote control.
Patented Anti-Burn-in™ Technology
To combat the effects of traditional LCD burn-in or ghosting, AG Neovo utilises its patented Anti-Burn-in Technology to prevent image burn-in and assure the extended life span for displays.
PID Command & Ctrl Software
PID Command & Ctrl provides intuitive user interfaces for remote management via laptops and mobile devices and offers easy creation on video wall displays. The software also has simple colour calibration, temperature check, IR/key locking options, and time on usage monitoring for daily maintenance.
| Beeldscherm | |
| Soort paneel | VA |
| LED backlight | Ja |
| Beeldschermdiagonaal | 138,7 cm (54.6") |
| Display technologie | LCD |
| Resolutie | 3840 x 2160 Pixels |
| Helderheid | 700 cd/mý |
| HD type | 4K Ultra HD |
| Touchscreen | Nee |
| Responstijd | 5 ms |
| Typische contrastverhouding | 5000:1 |
| Kijkhoek, horizontaal | 178ø |
| Kijkhoek, verticaal | 178ø |
| Beeldscherm, aantal kleuren | 1,07 miljard kleuren |
| Pixel pitch | 0,315 x 0,315 mm |
| Aantal displays | 1 |
| Frequentiebereik horizontaal | 31 - 92 kHz |
| Frequentiebereik verticaal | 48 - 85 Hz |
| Waasniveau | 25 procent |
| Hardheid oppervlak | 3H |
| Kleurbereik | 72 procent |
| Poorten & interfaces | |
| Aantal HDMI-poorten | 3 |
| HDMI versie | 2.0 |
| DVI-poort | Ja |
| DVI-I poorten | 1 |
| Aantal DisplayPorts | 2 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| USB-poort | Ja |
| Aantal USB-aansluitingen | 2 |
| USB-versie | 2.0 |
| Ethernet LAN | Ja |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Wifi | Nee |
| RS-232 | Ja |
| Infrarood datapoort | Ja |
| Remote (IR) ingang | 1 |
| Remote (IR) uitgang | 1 |
| Ge‹ntegreerde geheugenkaartlezer | Ja |
| Compatibele geheugenkaarten | MicroSD (TransFlash) |
| Audio | |
| Ingebouwde luidsprekers | Ja |
| Aantal ingebouwde luidsprekers | 2 |
| Gemiddeld vermogen | 10 W |
| Design | |
| Productontwerp | Digitale signage flatscreen |
| Ondersteuning voor plaatsing | Binnen |
| Model | Horizontaal/Verticaal |
| Kleur van het product | Zwart |
| VESA-montage | Ja |
| Paneelmontage-interface | 400 x 400 mm |
| Antireflectiescherm | Ja |
| Prestatie | |
| Bedoeld voor | Universeel |
| Ge‹ntegreerde TV Tuner | Nee |
| Bedrijfsuren (uren/dagen) | 24/7 |
| Energie | |
| Stroomverbruik (typisch) | 177 W |
| Stroomverbruik (in standby) | 0,5 W |
| Energie-effici‰ntieklasse (SDR) | G |
| Energieverbruik (SDR) per 1000 uur | 177 kWu |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Energie-effici‰ntieschaal | A tot G |
| Computersysteem | |
| Computersysteem | Ja |
| Type processor | Nee |
| Gewicht en omvang | |
| Schermbreedte | 1247,8 mm |
| Display diepte | 63,6 mm |
| Display hoogte | 712,6 mm |
| Display gewicht | 16,6 kg |
| Warranty | |
| Base Warranty | Non Non |
| Verpakking | |
| Breedte verpakking | 1350 mm |
| Diepte verpakking | 160 mm |
| Hoogte verpakking | 860 mm |
| Gewicht verpakking | 21,8 kg |
| Inhoud van de verpakking | |
| Afstandsbediening inbegrepen | Ja |
| Batterijen inbegrepen | Ja |
| Meegeleverde kabels | AC, HDMI |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 20 - 80 procent |
| Temperatuur bij opslag | -20 - 60 øC |
| Luchtvochtigheid bij opslag | 10 - 90 procent |
| Certificaten | |
| Certificering | FCC CE LVD ICES-003(Issue 7) WEEE RoHS REACH |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85285210 |
| Kenmerken | |
| Ophangsysteem voor aan de muur | Ja |
| Technische details | |
| Aansluitingen | SDM Slot |
| Certificaten van naleving | RoHS |
| Overige specificaties | |
| Snelstartgids | Ja |
| Audio-ingangen | 1 |
| Audio-uitgang | 1 |
| RS-232 ingangspoorten | 1 |
| RS-232 uitgangspoorten | 1 |
