DisplayPort To Vga Adapter Converter - Dp To Vga - 1m Black
ITCurry #: 75646005 | Article #: DP2VGAMM3B-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Connect a DisplayPort-equipped PC to a nearby VGA monitor/Projector, with a short 3 foot cable
The DP2VGAMM3B active DisplayPort to VGA converter cable lets you connect your DisplayPort-equipped desktop or laptop directly to a nearby VGA monitor or projector, saving the expense of additional adapters while eliminating the clutter of excess cable.
Plus, because the converter cable supports video resolutions up to 1920x1200 you can convert a DisplayPort video source to VGA without sacrificing video quality.
The DP2VGAMM3B is backed by a 3-year StarTech.com warranty and free lifetime technical support.
The StarTech.com Advantage
Features | |
Connector 1 form factor | Straight |
Connector 2 form factor | Straight |
Cable length | 0.91 m |
Connector 1 | DisplayPort |
Connector 2 | VGA (D-Sub) |
Connector 1 gender | Male |
Connector 2 gender | Male |
DisplayPort version | 1.2 |
Maximum resolution | 2048 x 1280 pixels |
Supported graphics resolutions | 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1280 |
Maximum refresh rate | 60 Hz |
HBR2 support | Yes |
Product colour | Black |
Chipset | Analogix - 9832 |
Plug and Play | Yes |
Converter type | Active video converter |
Operational conditions | |
Operating temperature (T-T) | 0 - 60 øC |
Storage temperature (T-T) | -10 - 70 øC |
Operating relative humidity (H-H) | 40 - 85% |
Weight & dimensions | |
Weight | 79 g |
Width | 40 mm |
Depth | 915 mm |
Height | 15 mm |
Packaging data | |
Quantity per pack | 1 pc(s) |
Package width | 160 mm |
Package depth | 240 mm |
Package height | 20 mm |
Package weight | 90 g |
Technical details | |
Compliance certificates | CE, RoHS |
Logistics data | |
Harmonized System (HS) code | 84733080 |
Master (outer) case width | 420 mm |
Master (outer) case length | 415 mm |
Master (outer) case height | 435 mm |
Products per master (outer) case | 220 pc(s) |
Warranty | |
Base Warranty | Non Non |
