CV5000DP USB-C 4K/8K DisplayPort 1.4 Adapter
ITCurry #: 29056125 | Article #: K34680WW-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Today’s ultra-thin laptops often only feature USB-C or Thunderbolt ports with no dedicated video outputs. This can make the addition of accessories and peripherals a chore, particularly for users wishing to connect to an external monitor. The CV5000DP USB-C 4K/8K DisplayPort 1.4 Adapter allows any device with a USB-C, USB4, Thunderbolt 3, or Thunderbolt 4 port to connect to a DisplayPort monitor quickly and easily. Supporting up to 8K video and compatible with Windows, macOS, and Chrome OS, this compact adapter is perfect for the on-the-go hybrid worker moving home and office, who wishes to work on an external monitor to enhance their productivity.
Supports 8K Video for Stunning Video Quality
Easily add an additional DisplayPort monitor to your setup. This DP 1.4 adapter supports monitors and projectors up to 4K @ 120Hz, and 8K @ 30Hz. Backward compatible with 1080p @ 60Hz, this adapter can easily connect to legacy DisplayPort monitors as well. (The USB-C port on your device must support DisplayPort Alt Mode.)
Universally Compatible
Works with Windows 10 or later, macOS 11 or later, and Chrome OS 44 or later.
Helps Future Proof Your Setup
Designed to work with the latest technology, this adapter works perfectly with USB-C, Thunderbolt 3, Thunderbolt 4, and USB4 devices.
Driverless, Plug and Play
Simply plug in the adapter and it will run automatically, without the need for drivers or software downloads.
Compact Design
The small footprint of the adapter makes it easy to use and take on the go.
Premium Construction
Made with premium components and tested to meet and exceed Kensington’s high standards, this adapter is built to last.
| Performance | |
| USB connector type | USB Type-C |
| USB connector gender | Male |
| USB connector form factor | Straight |
| DVI output | No |
| HDMI output | No |
| DisplayPort output | Yes |
| Number of displays supported | 1 |
| DisplayPorts quantity | 1 |
| HDCP | Yes |
| HDCP version | 1.4/2.2 |
| DisplayPort version | 1.4 |
| Maximum resolution | 7680 x 4320 pixels |
| Refresh rate at maximum resolution | 30 Hz |
| Design | |
| Product colour | Black |
| Housing material | Plastic |
| Integrated USB cable | Yes |
| Cable type | Round cable |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64 |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia |
| Other operating systems supported | ChromeOS |
| Weight & dimensions | |
| Width | 54 mm |
| Depth | 22 mm |
| Height | 11 mm |
| Weight | 18 g |
| USB cable length | 0.121 m |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 øC |
| Storage temperature (T-T) | -10 - 70 øC |
| Operating relative humidity (H-H) | 10 - 85% |
| Packaging data | |
| Package width | 25 mm |
| Package depth | 119 mm |
| Package height | 79 mm |
| Package weight | 50 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, VCCI |
| Logistics data | |
| Products per master (outer) case | 10 pc(s) |
| Country of origin | China, Vietnam |
| Warranty | |
| Base Warranty | Non Non |
