USB-c To DisplayPort Adapter Cable, 8k 60hz, 4k 144hz, Hdr, USB Type-c To Dp 1.4 Video Converter Cable 3m
ITCurry #: 7564C012 | Article #: 142-USBC-DP-8K-10F-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Connect a DisplayPort Alt Mode-enabled USB-C source to a DisplayPort monitor with support for resolutions up to 8K at 60HzConnect an 8K 60Hz or 4K 144Hz DisplayPort monitor to a DP Alt Mode-enabled USB Type-C source up to 9.8ft (3m) away with this USB-C to DisplayPort adapter cable.High-Resolution HDR VideoThis USB-C to DisplayPort Cable enables resolutions of up to 8K 60Hz and is DisplayPort 1.4 compliant. It supports HDR10, DSC, and 2 channel audio.Hardware PlatformSingle MonitorDisplayPort Alt ModeIntel 11th Gen & Later Processors8K 60Hz or 4K 144Hz*DisplayPort 1.4Nvidia RTX3000 and AMD RX6000 or later8K 60Hz or 4K 144HzDisplayPort 1.4Intel 10th Gen & Earlier4K 60HzDisplayPort 1.4Apple M1/M2/M3 + Pro & Max4K 60Hz**DisplayPort 1.4*DSC support required to reach maximum resolution capabilities on Intel 11th Gen or later**Apple MacBook's with M1/M2/M3 Pro/Max silicon do not support 8K 60Hz over USB-C DP Alt ModeUniversal CompatibilityThe USB-C to DisplayPort Converter Cable is compatible with laptops and devices from various brands such as Dell, HP, Lenovo, Microsoft, and more. It works with all hardware platforms and any operating system. The USB Type-C to DisplayPort Cable requires no drivers or software and works with USB-C DP Alt Mode, USB4, Thunderbolt 3, and Thunderbolt 4 laptops and devices.Thoughtfully DesignedCombining a video adapter and cable minimizes potential points of failure and signal loss. A latching DisplayPort connector reduces the risk of accidental disconnections. The cable is equipped with aluminum connector shells, providing enhanced durability, and shielding from Electromagnetic Interference (EMI).The StarTech.com Advantage
Features | |
Connector 1 form factor | Straight |
Connector 2 form factor | Straight |
Cable length | 3 m |
Connector 1 | USB Type-C |
Connector 2 | DisplayPort |
Connector 1 gender | Male |
Connector 2 gender | Male |
HDCP | Yes |
HDCP version | 1.4/2.2/2.3 |
DisplayPort version | 1.4 |
USB Type-C DisplayPort Alternate Mode | Yes |
High Dynamic Range (HDR) supported | Yes |
Supported graphics resolutions | 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768, 1280 x 768 (WXGA), 1280 x 800, 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 2560 x 1080, 3440 x 1440, 3840 x 2160, 4096 x 2160, 5120 x 1440, 5120 x 2880, 7680 x 4320 |
Bandwidth | 32400 MB/s |
Maximum refresh rate | 144 Hz |
Refresh rate at maximum resolution | 60 Hz |
Product colour | Black, Grey |
Chipset | VL103 |
Jacket material | Thermoplastic elastomer (TPE) |
Cable type | Round cable |
Plug and Play | Yes |
Latching connectors | Yes |
Operational conditions | |
Operating temperature (T-T) | -20 - 70 øC |
Storage temperature (T-T) | -40 - 70 øC |
Operating relative humidity (H-H) | 5 - 95% |
Sustainability | |
Sustainability compliance | Yes |
Sustainability certificates | RoHS |
Weight & dimensions | |
Cable diameter | 4.3 mm |
Weight | 111 g |
Packaging data | |
Package width | 150 mm |
Package depth | 100 mm |
Package height | 100 mm |
Package weight | 80 g |
Technical details | |
Compliance certificates | RoHS |
Logistics data | |
Master (outer) case width | 300 mm |
Master (outer) case length | 300 mm |
Master (outer) case height | 350 mm |
Products per master (outer) case | 100 pc(s) |
Warranty | |
Base Warranty | Non Non |
