Montior arm with notebook tray 17-32in, 9 kg. Max., clamp or grommet mount
ITCurry #: M9238806 | Article #: DA-90436-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The desktop mount offers you the option of aligning a monitor of up to 32" / 9 kg and a notebook of up to 15.6" / 4 kg individually, space-savingly and ergonomically
- Suitable for (curved) monitors up to 32" / 9 kg max.
- Suitable for notebooks up to 15.6" / 4 kg max.
- Integrated cable management
- Two mounting options: both table clamp and feed-through rod are included in the scope of delivery
- Quick-release fastener: VESA plate can be fixed/released with a screw when mounting and dismounting
- Height-adjustable, rotate, swivel
- Adjustable notebook holder offers a secure hold
- VESA compatibility: 75x75, 100x100
- Monitor arms: Tilt: -45°/+45°, swivel: -90°/+90°, front panel rotatable: -180°/+180°
- Tested & certified ergonomic product - Certified by IGR (Institute for Health and Ergonomics)
The desktop mount offers you the option of aligning a monitor of up to 32" / 9 kg and a notebook of up to 15.6" / 4 kg individually, space-savingly and ergonomically. The VESA mount supports: 75 x 75, 100 x 100 mounts. The mount offers two mounting options: both table clamp and grommet bar. Thanks to the quick-release fastener, the VESA plate can be attached and detached using a screw. The integrated cable management ensures a tidy workplace.
| Mounting | |
| Maximum weight capacity | 9 kg |
| Minimum screen size | 43.2 cm (17") |
| Number of displays supported | 1 |
| Maximum screen size | 81.3 cm (32") |
| Mounting | Clamp |
| Mounting type | Desk |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Ergonomics | |
| Height adjustment | Yes |
| Height adjustment type | Manual |
| Tilt adjustment | Yes |
| Tilt angle range | -45 - 45ø |
| Swivel angle range | -90 - 90ø |
| Angle of rotation | 360ø |
| Feet | Yes |
| Feet colour | Black |
| Design | |
| Housing material | Plastic, Steel |
| Product colour | Black |
| Easy to install | Yes |
| Weight & dimensions | |
| Weight | 4.75 kg |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 443 mm |
| Package depth | 298 mm |
| Package height | 113 mm |
| Package volume | 14917.6 cmü |
| Package weight | 6 kg |
| Package type | Box |
| Packaging content | |
| Clamp included | Yes |
| VESA mount included | Yes |
| Mounting kit | Yes |
| Logistics data | |
| Country of origin | China |
| UK Trade Tariff code | 73269098 |
| Warranty | |
| Base Warranty | Non Non |
