Industrial 8-Port Gigabit Switch 8x 10/100/1000Base-TX Ethernet Ports
ITCurry #: M9237767 | Article #: DN-651108-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
- Industrial 8-port Gigabit switch
- 8 x 10/100/1000Base-TX Ethernet ports
- Extended operating temperature range, -40 °C ~ +75 °C
The DIGITUS® Industrial Gigiabit Switch is designed for harsh environments where they are exposed to humidity, temperature fluctuations and vibrations. With a temperature range of -40°C to 75°C, the Industrial Gigabit Switch can be used under the most adverse conditions. Constant availability is guaranteed in highly sensitive areas such as transportation, production, traffic and security surveillance. Thanks to the simple plug-and-play system, the Industrial Gigabit Switch can be quickly integrated into the respective environment. Gigabit connectivity makes the Industrial Gigabit Switch a flexible, cost-effective solution for industrial environments.
| Management features | |
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-TX |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| VLAN support | No |
| Data transmission | |
| Switching capacity | 16 Gbit/s |
| MAC address table | 8000 entries |
| Store-and-forward | Yes |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| Wall mountable | Yes |
| DIN rail mounting | Yes |
| Vandal-proof | No |
| Suitable for outdoor use | No |
| Performance | |
| Plug and Play | Yes |
| Mean time between failures (MTBF) | 500000 h |
| Power | |
| Redundant power supply (RPS) support | Yes |
| DC input voltage | 12 - 56 V |
| Power consumption (typical) | 5 W |
| Power protection features | Over voltage, Short circuit |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Other features | |
| Ethernet interface type | Gigabit Ethernet |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 85 øC |
| Weight & dimensions | |
| Width | 36.2 mm |
| Depth | 105 mm |
| Height | 142 mm |
| Weight | 520 g |
| Packaging content | |
| Quick start guide | Yes |
| Packaging data | |
| Terminal block included | Yes |
| Package width | 65 mm |
| Package depth | 165 mm |
| Package height | 215 mm |
| Package volume | 2305.88 cmü |
| Package weight | 787.5 g |
| Certificates | |
| Certification | EN 50155 |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Country of origin | Taiwan |
| Master (outer) case width | 240 mm |
| Master (outer) case length | 350 mm |
| Master (outer) case height | 560 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case gross weight | 12.6 kg |
| Master (outer) case volume | 47040 cmü |
| Products per master (outer) case | 16 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
