Industrial 5-Port Gigabit Switch 5 x 10/100/1000Base-TX Ethernet Ports
ITCurry #: M9237793 | Article #: DN-651107-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Standard / Din Rail mounting dual purpose
- Industrial 5-Port Gigabit Switch
- 5 x 10/100/1000Base-TX Ethernet Ports
- Extended operating temperature range, -40 °C ~ +85 °C
The DIGITUS® Industrial Gigabit Switch is designed for harsh environments, where it is exposed to moisture, temperature fluctuations, and vibrations. With a temperature range of -40°C to 85°C, the Industrial Gigabit Switch can be used under the most adverse conditions. It ensures a constant availability in highly sensitive areas such as transport, production, traffic and safety monitoring. The simple plug and play system allows the Industrial Gigabit Switch to be quickly integrated into the respective environment. With its Gigabit connectivity the Industrial Gigabit Switch is a flexible, cost-effective solution for the industrial environment.
| Warranty | |
| Base Warranty | Non Non |
| Management features | |
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| VLAN support | No |
| Data transmission | |
| Switching capacity | 10 Gbit/s |
| MAC address table | 8000 entries |
| Store-and-forward | Yes |
| Security | |
| MAC address filtering | Yes |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| Wall mountable | Yes |
| DIN rail mounting | Yes |
| Vandal-proof | No |
| Suitable for outdoor use | No |
| Country of origin | Taiwan |
| Performance | |
| Mean time between failures (MTBF) | 500000 h |
| Power | |
| Redundant power supply (RPS) support | Yes |
| DC input voltage | 18 - 36 V |
| Power consumption (typical) | 2.76 W |
| Power protection features | Over voltage, Reverse polarity, Short circuit |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 85 øC |
| Packaging data | |
| Package width | 65 mm |
| Package depth | 165 mm |
| Package volume | 2305.88 cmü |
| Package weight | 462.5 g |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| Ethernet interface type | Gigabit Ethernet |
