Fast Ethernet PoE af/at 8 port switch + 2 uplinks 120W PoE power budget, rack mountable
ITCurry #: M9237929 | Article #: DN-95323-1-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Network Switch with integrated Power over Ethernet (PoE) solution for an optimal, cost effective and fast integration in small or medium-sized networks
- 8-port 10/100Base-TX with PoE support
- 2-port Fast Ethernet uplink
- Meets the network standards IEEE 802.3, IEEE802.3u, IEEE802.3q, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at
- The VLAN mode provides a port-based VLAN function that prevents multicast or broadcast requests from interfering with each other
- The Extensive mode offers range extension of up to 250 m at 10 Mbps
- Maximum PoE power of 120 watts
Fast Ethernet PoE Switch,8-port PoE + 2-port uplink, 120W PoE budget
Management features | |
Switch type | Unmanaged |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Network | |
Networking standards | IEEE 802.3at |
10G support | No |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
VLAN support | No |
Data transmission | |
Switching capacity | 2 Gbit/s |
MAC address table | 8000 entries |
Store-and-forward | Yes |
Multicast features | |
Multicast support | Yes |
Design | |
Rack mounting | Yes |
Product colour | Grey |
LED indicators | Yes |
Vandal-proof | No |
Suitable for outdoor use | No |
Country of origin | China |
Power | |
Power supply included | Yes |
Power consumption (max) | 125 W |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 8 |
Total Power over Ethernet (PoE) budget | 120 W |
Packaging data | |
Cables included | AC |
Quick start guide | Yes |
Package width | 310 mm |
Package depth | 200 mm |
Package volume | 4960 cmü |
Package weight | 1.94 kg |
Logistics data | |
UK Trade Tariff code | 85176200 |
Harmonized System (HS) code | 85176990 |
Other features | |
Ethernet interface type | Fast Ethernet |
Warranty | |
Base Warranty | Non Non |
