Dockstation Vga Sensevision 4k USB 3.0
ITCurry #: M4192711 | Article #: CSV-3104D-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The Club 3D USB 3.0 4K UHD Mini Docking Station with brushed aluminum design, allows you to expand the outputs of your laptop or ultrabook so it can be used as a traditional desktop PC.
With the advanced DisplayLink DL-5900 chip inside, Club3D’s USB 3.0 4K UHD Mini Docking Station is able to offer you the perfect solution to connect all your favorite USB devices (*4), as well as connect two external monitors via HDMI™ and a DVI-D Connector, in addition to an Ethernet network Connection it also offers an Audio/Microphone output all via a single USB cable.
Because of its convenient and compact design, the Club 3D USB 3.0 4K UHD Mini Docking Station is a versatile tool that provides you maximum functionality from your Small desktop replacement or mobile companion.
Design:
The Club3D USB 3.0 4K UHD Mini Docking Station has a modern and minimalistic design and combines the functionality normally found in larger Docking Stations with a convenient, solid and highly portable casing. The miniature size makes it easy to take it with you wherever you go. Use it without external power for maximum mobility*. (*Limits functionality)
| Ports & interfaces | |
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DVI-D ports quantity | 1 |
| Microphone in | Y |
| Combo headphone/mic port | Y |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| Line-out | Y |
| DC-in jack | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Performance | |
| Card reader integrated | N |
| Maximum digital resolution | 3840 x 2160 pixels |
| Number of displays supported | 2 |
| Product colour | Black, Silver |
| LED indicators | Power |
| Charging function | Y |
| Housing material | Aluminium |
| Compatibility | Lenovo Dell Acer Asus. MSI. Toshiba Apple HP Razer |
| Power | |
| Power source type | DC |
| Output voltage | 12 V |
| Output current | 3 A |
| Power consumption (max) | 36 W |
| Power consumption (typical) | 14.43 W |
| Software | |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 95 mm |
| Depth | 49 mm |
| Height | 44 mm |
| Weight | 260 g |
| Packaging data | |
| Package width | 225 mm |
| Package depth | 142 mm |
| Package height | 55 mm |
| Packaging content | |
| Cables included | USB |
| AC adapter included | Y |
| Quick start guide | Y |
| Drivers included | Y |
| Technical details | |
| Harmonized System (HS) code | 84733020 |
| Other features | |
| Number of microphone inputs | 1 |
| Warranty | |
| Base Warranty | Non Non |
