Q1809-le Bullet Camera
ITCurry #: 13836718 | Article #: 02870-001-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Ideal for long distance surveillance, this all-in-one, outdoor-ready bullet camera delivers superior image quality in 41 MP with high light sensitivity and extremely high pixel density.
See all the details
Built on a dual Axis system-on-chip, this device delivers extreme detail over great distances and excellent forensic value. It offers 41 MP at 15 fps or 8K at up to 30 fps. And a 4/3” image sensor ensures exceptional low-light performance. With a custom-made, tele Canon lens, it’s perfect for long-distance surveillance and delivers extremely high pixel density. Electronic image stabilization (EIS) ensures smooth video in situations where a camera is subject to vibrations, for instance, at sports arenas or windy harbors. Furthermore, Axis Zipstream reduces bandwidth and storage requirements without compromising image quality.
All-in-one and ready for everything
This powerful camera offers everything you need and is out-of-the-box ready to use. Enclosed in a robust aluminum casing, it also includes a mounting arm for easy installation. And a spacious back box ensures secure cable management. It features a custom-made, tele (50 – 150 mm) Canon lens and 21°-7° horizontal field of view. With 3x zoom, it’s ideal for identification purposes. In addition, thanks to PoE out, you can connect and power another device without any additional cabling. This eliminates the need to rent extra ports and simplifies installation.
Secure and robust surveillance
AXIS Q1809-LE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. This robust, weather-protected, outdoor-ready camera is IP66-, IP67-, IK10- and NEMA 4X-rated and features a IK08-rated impact-resistant glass front window. It has an operating temperature range from -40 °C to 55 °C (-40 °F to 131 °F). Furthermore, surge protection minimizes damage in the case of a power surge.
| Performance | |
| Type | IP security camera |
| Placement supported | Outdoor |
| Connectivity technology | Wired |
| PTZ control | Yes |
| PTZ modes | Digital PTZ |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Certification | CSA, UL/cUL, CE, EAC, VCCI, RCM |
| Design | |
| Form factor | Bullet |
| Mounting type | Ceiling/wall |
| Product colour | Black, White |
| Housing material | Aluminium, Glass |
| Protection features | Impact resistant |
| International Protection (IP) code | IP66, IP67 |
| IK code | IK10 |
| Camera | |
| Minimum illumination | 0.04 lx |
| Angle of rotation | 270ø |
| Lens viewing angle, horizontal | 90 - 44ø |
| Lens viewing angle, vertical | 49 - 25ø |
| Tilt angle range | 0 - 90ø |
| Pan range | -180 - 180ø |
| Camera pixel size | 2.315 æm |
| Camera shutter speed | 1/15500 - 2 s |
| Image sensor | |
| Number of sensors | 1 |
| Optical sensor size | 101.6 / 3 mm (4 / 3") |
| Sensor type | CMOS |
| Lens system | |
| Zoom capability | Yes |
| Number of lenses | 1 |
| Focal length range | 12 - 24 mm |
| Focus | Motorized |
| Maximum aperture number | 4 |
| Detect distance (wide) | 853.8 m |
| Detect distance (tele) | 2551.6 m |
| Observe distance (wide) | 338.8 m |
| Observe distance (tele) | 1012.6 m |
| Recognize distance (wide) | 170.8 m |
| Recognize distance (tele) | 510.2 m |
| Identify distance (wide) | 85.4 m |
| Identify distance (tele) | 255.2 m |
| Closest focusing distance | 5 m |
| Night vision | |
| Night vision | Yes |
| LED type | IR |
| Infra-red wavelength | 900 nm |
| Video | |
| Maximum resolution | 7680 x 4320 pixels |
| Total megapixels | 41 MP |
| Video formats supported | AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Video compression formats | H.264, H.265 |
| Supported graphics resolutions | 160 x 120, 160 x 90, 1280 x 800, 3840 x 2160 |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Noise reduction | Yes |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Gain control type | Auto |
| Image quality adjustment | Brightness, Contrast, Mirror, Sharpness |
| Text caption overlay | Yes |
| Image stabilizer | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Audio | |
| Audio formats supported | AAC-LC, ADPCM, G.711, G.726, LPCM, PCM |
| Sample rate | 48 kHz |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Network | |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.1AE, IEEE 802.1x |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSd , HTTP/2, TLSd , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP© , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Wi-Fi | No |
| Bluetooth | No |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Storage | |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 8192 MB |
| ROM capacity | 4096 MB |
| Ports & interfaces | |
| Microphone in | Yes |
| Terminal block port | Yes |
| DC-in jack | Yes |
| Security | |
| Password protection | Yes |
| Security algorithms | EAP-TLS, HTTPS |
| Alert notification type | |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Management features | |
| Cloud-managed | Yes |
| Remotely operated | Yes |
| Power | |
| Power source type | DC, PoE |
| Power consumption (typical) | 17.6 W |
| Power consumption (max) | 35 W |
| Power consumption (Power over Ethernet (PoE)) | 18.9 W |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 55 øC |
| Storage temperature (T-T) | -40 - 65 øC |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Depth | 411 mm |
| Height | 183 mm |
| Diameter | 18.3 cm |
| Weight | 3.2 kg |
| Sustainability | |
| Compliance certificates | REACH, RoHS |
| Packaging content | |
| Number of cameras | 1 |
| Warranty | |
| Base Warranty | Non Non |
