Product Information
Ideal for tough environments and rough weather, AXIS M2036-LE delivers Quad HD 1440p/4 MP. With a deep learning processing unit, it enables unique opportunities for analytics based on deep learning on the edge. AXIS Object Analytics offers detection and classification of humans, vehicles, and types of vehicles. And Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network. This IK08-rated camera offers flexible and cost-efficient installation including support for PoE. Edge-to-edge technology allows for smart pairing with Axis Speakers. Plus, a spacious, sealed back box ensures secure cable management.
Performance | |
Type | IP security camera |
Placement supported | Outdoor |
Connectivity technology | Wired |
PTZ modes | Digital PTZ |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Infrared (IR) cut-off filter | Yes |
Number of languages | 12 |
Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
Certification | CISPR 24, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A IEC/EN 62368-1, IEC 62471, IS 13252 IEC 60068-2-X, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK08 NIST SP500-267 |
Design | |
Form factor | Bullet |
Mounting type | Ceiling/wall |
Product colour | White |
Housing material | Aluminium, Plastic |
Protection features | Dust resistant, Vandal proof, Water resistant |
International Protection (IP) code | IP66, IP67 |
IK code | IK08 |
Camera | |
Lens viewing angle, horizontal | 130ø |
Lens viewing angle, vertical | 81ø |
White balance | Auto |
Camera shutter speed | 1/38500 - 1/5 s |
Image sensor | |
Sensor type | CMOS |
Lens system | |
Number of lenses | 1 |
Maximum aperture number | 2.1 |
Fixed focal length | 2.4 mm |
Closest focusing distance | 0.5 m |
Night vision | |
Night vision | Yes |
Night vision distance | 20 m |
LED type | IR |
Infra-red wavelength | 855 nm |
Video | |
Maximum resolution | 2304 x 1728 pixels |
Total megapixels | 4 MP |
Video compression formats | H.264, H.265, M-JPEG |
Supported graphics resolutions | 2668 x 1512, 2304 x 1728 |
Supported video modes | 1440p |
Video recording | Yes |
Video intelligence analytic | Yes |
Video streaming | Yes |
Privacy masking | Yes |
Text caption overlay | Yes |
Image stabilizer | Yes |
Network | |
Ethernet LAN | Yes |
Ethernet interface type | Fast Ethernet |
Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP©, SNMP v1/v2c/v3 (MIB-II), DNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SOCKS, SSH, LLDP, MQTT v3.1.1 |
Quality of Service (QoS) support | Yes |
Storage | |
Built-in HDD | No |
Card reader integrated | Yes |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC |
Flash memory | 512 MB |
Internal memory | 1024 MB |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 1 |
Security | |
Password protection | Yes |
Video motion detection | Yes |
Active tampering alarm | Yes |
IP address filtering | Yes |
Security algorithms | 802.1x RADIUS, EAP-TLS, HTTPS, SSH |
HTTPS encryption | Yes |
Alert notification type | |
Power | |
Power source type | PoE |
Power consumption (typical) | 5 W |
Power consumption (max) | 12.95 W |
Operational conditions | |
Operating temperature (T-T) | -30 - 50 øC |
Storage temperature (T-T) | -40 - 65 øC |
Operating relative humidity (H-H) | 10 - 100% |
Weight & dimensions | |
Diameter | 10.1 cm |
Length | 170 mm |
Weight | 491 g |
Packaging content | |
Number of cameras | 1 |
Other features | |
Doesn't contain | BFR, PVC |
Logistics data | |
Harmonized System (HS) code | 85258900 |
Warranty | |
Base Warranty | Non Non |
