True 4k Hdmi Edid Emulator Adapter
ITCurry #: 90314005 | Article #: VC081A-AT-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
As a True 4K HDMI EDID Emulator Adapter , the VC081A is designed to emulate and store one set of the EDID from the connected display while facilitating 4K video transmission. By learning the EDID from the HDMI display and relaying it to the video source, the VC081A helps to eliminate video communication problems that occur due to the EDID data synchronization failure between the HDMI video source and the connected display.
This new member contains a unique “Learn Button Switch” to allow EDID to be effectively learned and saved. Once the EDID is learned, the VC081A can be used to keep a PC or server awake from a remote location over IP instead of the monitor. The VC081A is an ideal device for avoiding blank or blink display issues led by communication errors between sources and displays when integrating a Pro AV system.
| Features | |
| Maximum video resolution | 3840 x 2160 pixels |
| Consumer Electronics Control (CEC) support | Yes |
| Design | |
| Product colour | Black |
| Housing material | Plastic |
| LED indicators | Yes |
| Ports & interfaces | |
| Video port type | HDMI |
| Number of video inputs | 1 |
| Number of video outputs | 1 |
| HDCP | Yes |
| Logistics data | |
| Products per master (outer) case | 20 pc(s) |
| Master (outer) case gross weight | 1.64 kg |
| Master (outer) case length | 260 mm |
| Master (outer) case width | 245 mm |
| Master (outer) case height | 285 mm |
| Master (outer) case net weight | 160 g |
| Weight & dimensions | |
| Width | 44 mm |
| Depth | 24 mm |
| Height | 11.8 mm |
| Weight | 8 g |
| Packaging data | |
| Quick start guide | Yes |
| Package width | 42 mm |
| Package depth | 124 mm |
| Package height | 129 mm |
| Package weight | 82 g |
| Warranty | |
| Base Warranty | Non Non |
