The VE1830 True 4K HDMI HDBaseT-Lite Extender provides great flexibility in professional A/V installation with its high-quality transmitter VE1830T and receiver VE1830R. Powered by HDBaseT™ technology, the VE1830 transmits True 4K HDMI signals up to 35m using a single Cat 5e/6 cable. ThisHDBaseT-Lite Extender supports HDCP 2.2 and meets the HDMI 2.0a specifications (3D, Deep Color, 4k) to ensure visually loseless high quality video and image. In addition, it features PoC (Power over Cable) which can power the receiver unit from the transmitter side with power supply. The VE1830 offers an easy-to-use and cost-effective solution for professional A/V installations that require superior HDMI video quality, such as in digital classrooms, video conference rooms and home theater.
1x VE1830T True 4K HDMI HDBaseT-Lite Transmitter
1x VE1830R True 4K HDMI HDBaseT-Lite Receiver
2x RS-232 Terminal Blocks
1x 0AD8-8F12-33MG Power Adapter
1x LIN2-418K-E12G Power Cord
1x Mounting Kit
1x User Instructions
| Features | |
| Type | AV transmitter & receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6, Cat6a |
| Maximum transfer distance | 5 m |
| Maximum refresh rate | 60 Hz |
| Bandwidth | 10.2 Gbit/s |
| Bandwidth | 340 MHz |
| On/off switch | Yes |
| HDCP | Yes |
| Material | Metal |
| Firmware upgradeable | Yes |
| Impedance | 100 O |
| HDCP version | 2.2 |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| HDMI version | 2.0 |
| DC-in jack | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Weight | 800 g |
| Receiver dimensions (WxDxH) | 71.9 x 118.9 x 16.8 mm |
| Receiver weight | 120 g |
| Transmitter dimensions (WxDxH) | 71.9 x 118.9 x 16.8 mm |
| Transmitter weight | 150 g |
| Packaging data | |
| Package width | 100 mm |
| Package depth | 283 mm |
| Package height | 173 mm |
| Package weight | 1 kg |
| Technical details | |
| Sustainability certificates | RoHS |
| Compliance certificates | RoHS |
| Logistics data | |
| Master (outer) case width | 292 mm |
| Master (outer) case length | 517 mm |
| Master (outer) case height | 194 mm |
| Master (outer) case gross weight | 4.56 kg |
| Master (outer) case net weight | 4 kg |
| Products per master (outer) case | 5 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
