Hdmi Over Cat 5 Splitter 4-port
ITCurry #: 90313131 | Article #: VS1804T-AT-G
Related products
Product Information
The VS1804T HDMI Over Cat 5 Splitter is a splitter designed to connect one source to 4 displays over a long distance. Incorporating suggested compatible receivers *, the VS1804T HDMI Over Cat 5 Splitter can be a complete solution ideal for any professional A/V installation that requires multimedia content to be delivered to multiple destinations located up to 60 m away from the source.
* Compatible Receiver Units:
VB802 HDMI Over Cat 5 Repeater – cadcadable up to five levels
VE800AR HDMI Receiver
VS1804T combined with VB802 and VE800AR units can transmit signals up to 300 m
The VS1804Tsolution is perfect for a wide range of applications:
- In-store or tradeshow digital signage
- Broadcasting information in public (news, airline or train arrival/departure information)
- Sporting events
- Theater and lecture rooms
- Company training facilities
| Ports & interfaces | |
| Video port type | HDMI |
| Video out | HDMI |
| Ethernet LAN (RJ-45) ports | 8 |
| Video ports quantity | 2 |
| Serial ports quantity | 1 |
| Consumer Electronics Control (CEC) support | Yes |
| DC-in jack | Yes |
| Features | |
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| 3D | Yes |
| Maximum operating distance | 60 m |
| Bandwidth | 225 MHz |
| Rack mounting | Yes |
| HDCP | Yes |
| Dolby technologies | DTS-HD Master Audio, Dolby TrueHD |
| Network | |
| Cable types supported | Cat5, Cat5e |
| Power | |
| AC input voltage | 5.3 V |
| Power consumption (typical) | 5.2 W |
| Weight & dimensions | |
| Width | 157.8 mm |
| Depth | 437.2 mm |
| Height | 44 mm |
| Weight | 2.33 kg |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 116 mm |
| Package depth | 540 mm |
| Package height | 233 mm |
| Package weight | 2.82 kg |
| Packaging content | |
| Manual | Yes |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Logistics data | |
| Master (outer) case net weight | 6.99 kg |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 375 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 9.28 kg |
| Products per master (outer) case | 3 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
