Xgs2220 54fp - L3 Access Nebulaflex Pro Switch Poe 960w - 48x 1g - 2x 10mg - 4x 10g Sfp+
ITCurry #: 62305841 | Article #: XGS2220-54FP-EU0101F-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Nebula Cloud-managed Layer 3 Enterprise Switch
The XGS2220 Series is a family of Layer 3 access Switches that consists of six models, including PoE, Non PoE and Fiber options. Non PoE models offer Gigabit desktop ports for everyday network access; PoE models allow flexible options with larger PoE budgets and a mix of 60 W and 30 W ports to power devices like the latest WiFi 6/6E Wireless Access Points; The Fiber model aims to achieve business connectivity for high fiber port density requirement.
Flexible 10G For Converged Networking Applications
On top of four 10G SFP+ uplinks, the XGS2220 Series comes with two additional 10G Multi-Gig RJ 45 ports to offer the flexibility to connect to servers, network storage, or other high speed network devices. Business can operate smoothly with the better extensibility and robust network infrastructure.
Multiple Power Budget options
PoE models come with 10 ports of PoE++ (IEEE 802.3bt) offering up to 60 W per port and 16-40 ports of PoE+ (IEEE 802.3at) delivering up to 30 W per port to meet a variety of applications, including the latest generation of Wireless Access Points.
Within the range, the 3 PoE models of 30HP, 54HP and 54FP can offer larger Power budgets of 400 W, 600 W and 960 W respectively, allowing flexibility in powering a full range of PoE devices efficiently for applications like VoIP, surveillance, high density networked AV applications and Zyxel’s compressive WiFi 6/6E AP portfolio.
Nebula, Manage It Your Way!
The support of NebulaFlex Pro allows you to easily switch management modes between standalone management and intuitive Nebula cloud managed mode with 1 YEAR Pro Pack bundled. Nebula provides both intuitive web interface and mobile App to deliver a streamlined experience for installation and management of your network, without additional cost for a software or hardware controller.
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L3 |
| Quality of Service (QoS) | Ja |
| ARP-inspectie | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 48 |
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
| Aantal 10G Ethernet (koper)poorten | 2 |
| Aantal ge‹nstalleerde SFP+ modules | 4 |
| Netwerk | |
| Netwerkstandaard | IEEE 802.3ab, IEEE 802.3bt, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.1p, IEEE 802.1s, IEEE 802.3x, IEEE 802.3at, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3az, IEEE 802.1x |
| 10G support | Ja |
| Routing entries | 64 |
| Data-uitwisseling | |
| Switchingcapaciteit | 216 Gbit/s |
| Verzending snelheid | 161 Mpps |
| MAC-adrestabel | 32000 entries |
| Jumbo Frames ondersteuning | Ja |
| Packet buffergeheugen | 2 MB |
| Beveiliging | |
| DHCP-functies | DHCP relay, DHCP server |
| IGMP snooping | Ja |
| IGMP-proxy | Ja |
| Authenticatie type | IEEE 802.1x, RADIUS, TACACS+ |
| Multicast-functies | |
| Multicast Listener Discovery (MLD) snooping | MLD v1/v2 |
| Protocollen | |
| GARP VLAN Registratieprotocol (GVRP) | Ja |
| Design | |
| Rack-montage | Ja |
| Prestatie | |
| Intern geheugen | 1024 MB |
| Flash memory | 64 MB |
| Mean time between failures (MTBF) | 298,735 uur |
| Energie | |
| Stroombron | AC |
| Vermogenstoevoer inclusief | Ja |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Vermogensverbruik (max) | 1161,6 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Ja |
| Hoeveelheid Power over Ethernet (PoE) ports | 50 |
| Totaal Power over Ethernet (PoE)-budget | 960 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -20 - 50 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 95 procent |
| Luchtvochtigheid bij opslag | 10 - 90 procent |
| Warmtedissipatie | 195,43 BTU/h |
| Gewicht en omvang | |
| Breedte | 441 mm |
| Diepte | 330 mm |
| Hoogte | 44 mm |
| Gewicht | 5 kg |
| Warranty | |
| Base Warranty | Non Non |
