Product Informatie
The Ultrastar Data60 storage platform is a key element of next-generation disaggregated storage and Software-Defined Storage (SDS) systems. The Ultrastar Data60 provides up to 1.2PB1 of raw storage using our 20TB SMR HDDs in a compact and efficient form factor. The Ultrastar Data60 addresses the demanding storage needs of large enterprise customers, storage OEMs, cloud service providers, as well as resellers/integrators requiring dense, shared HDD.
IsoVibe™ Vibration Isolation Technology
Precise cuts in the baseboard provide a suspension for the drives in the chassis, isolating them from transmitted vibration. The result is that consistent performance is maintained, even when all the drives are working hard.
ArcticFlow™ Thermal Zone Cooling Technology
By introducing cool air into the center of the chassis, drives operate at lower and more consistent temperatures than conventional systems. This results in lower fan speeds, reduced vibration, lower power consumption, quieter operation and ultimately higher reliability.
Western Digital Resource Manager
A GUI-based tool that enables real-time monitoring and management of the platform and provides a consolidated dashboard displaying the most critical information. Other views allow platform configuration, health monitoring, and maintenance.
| Opslagmedia | |
| Opslagdrives ge‹nstalleerd | Ja |
| Ge‹nstalleerde opslag-drive | HDD |
| Totale ge‹nstalleerde opslagcapaciteit | 264 TB |
| Ondersteunde types opslag-drives | HDD & SSD |
| Aantal storage drives ondersteund | 60 |
| Maximaal ondersteunde opslagcapaciteit | 1300 TB |
| Opslag schijf-interface | Serial Attached SCSI (SAS) III |
| Opslag schijfgrootte | 3.5" |
| Ondersteunde opslagstationinterfaces | SAS, SATA III |
| Overdrachtssnelheid | 12 Gbit/s |
| Hot-swap drive bays | Ja |
| Poorten & interfaces | |
| USB-aansluiting | Nee |
| Mini-SAS-hostpoort | Ja |
| Mini-SAS-hostpoort aantal | 12 |
| Design | |
| Type behuizing | Rack (4U) |
| Kleur van het product | Zwart |
| LED-indicatoren | Ja |
| Aantal ventilatoren | 6 ventilator(en) |
| Geluidsniveau | 72 dB |
| Overtollige fans ondersteuning | Ja |
| Prestatie | |
| Apparaatklasse | Grote bedrijven |
| Energie | |
| Aantal voedingen | 2 |
| Redundante voeding | Ja |
| AC-ingangsfrequentie | 50 / 60 Hz |
| Minimale systeemeisen | |
| Ondersteunt Linux | Ja |
| Ondersteunde server operating systems | Windows Server 2016, Windows Server 2019 |
| Gewicht en omvang | |
| Breedte | 447 mm |
| Diepte | 712 mm |
| Hoogte | 175 mm |
| Diskbehuizing gewicht | 23,7 kg |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 5 - 35 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 85 procent |
| Temperatuur bij opslag | -40 - 70 øC |
| Warranty | |
| Base Warranty | Non Non |
