Flash Storage Platform 2u24-24 3.84TB SAS 12gb/s 1dw/d
ITCurry #: T2793374 | Article #: 1ES0110-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The 2U24 Flash Storage Platform is a key element of next generation Software-Defined Storage (SDS) systems. It offers performance advantages as well as flexibility to improve compute-to-capacity ratio by decoupling available storage from CPU resources.
Flash Performance
Depending on the type of SSDs and the number of drives installed, the 2U24 Platform can be configured to deliver the performance you need.
Designed for Enterprise and the Cloud
The 2U24 Flash Storage Platform addresses the demanding storage needs of large enterprises and Cloud service providers. With performance of up to 4.7M IOPS, 23 GB/s and less than 1ms latency, the Platform is the ideal solution for accelerating enterprise workloads such as Database, Virtualization and Scale-Out configurations. The flash platform delivers up to 184TB storage capacity, can be connected to up to six hosts via the 12Gb/s SAS3 interface, and offers enterprise-specific features including:
- Enterprise-class High Availability: hot swappable SSDs, IO Modules, and PSUs
- Fully upgradeable: upgradeable firmware enables drive technology and capacity updates without impacting applications
| Opslagmedia | |
| Opslagdrives ge‹nstalleerd | Ja |
| Ge‹nstalleerde opslag-drive | SSD |
| Aantal storage drives ge‹nstalleerd | 24 |
| Totale ge‹nstalleerde opslagcapaciteit | 92,16 TB |
| Ondersteunde types opslag-drives | SSD |
| Aantal storage drives ondersteund | 24 |
| Maximaal ondersteunde opslagcapaciteit | 183,32 TB |
| Capaciteit opslag-drive | 3,84 TB |
| Opslag schijf-interface | Serial Attached SCSI (SAS) |
| Opslag schijfgrootte | 2.5" |
| Overdrachtssnelheid | 12 Gbit/s |
| Poorten & interfaces | |
| Mini-SAS-hostpoort | Ja |
| Design | |
| Type behuizing | Rack (2U) |
| Kleur van het product | Zilver |
| Overtollige fans ondersteuning | Ja |
| Prestatie | |
| Apparaatklasse | Kleine & middelgrote bedrijven |
| Energie | |
| Capaciteit voedingsunit (PSU) | 600 W |
| AC-ingangsspanning | 90-264 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Gewicht en omvang | |
| Breedte | 446 mm |
| Diepte | 536 mm |
| Hoogte | 87,4 mm |
| Gewicht | 23,7 kg |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 84717020 |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 5 - 40 øC |
| Relatieve vochtigheid in bedrijf (V-V) | -40 - 60 procent |
| Warranty | |
| Base Warranty | Non Non |
