Touch monitor - TD3207 - 32in - 1920x1080 (Full HD) - 5ms
ITCurry #: 11914008 | Article #: TD3207-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
OVERVIEW
The ViewSonic's TD3207 is the ideal solution for commercial and industrial spaces. Designed for heavy, continuous usage, the open frame series TD3207 delivers a 24/7 long-life. Resistant to moisture and scratches, the 3mm thick glass screen features an intuitive 10-point PCAP touch technology for maximum interactivity. Featuring SuperClear® AMVA panel technology, the device delivers lifelike imagery, vivid color, and constant brightness of up to 450 nits. Connection options include HDMI and DisplayPort inputs for effortless sharing capabilities and an RS232 allows you to control the device remotely. Equipped with VESA mounting design for any surface and screen orientation, the touch screen is the perfect display for various environments.
Why you should use ViewSonic's TD3207 ?
Accessible, durable, and contamination resistant, the 32" touch monitor is your one-stop solution for industrial, retail, and commercial applications. Whether it is a self-ordering kiosk or an industrial control automation, the device delivers stunning image quality, versatile installation modes and an intuitive 10-point touch response technology.
Supreme reliability and durability
Hard knocks, water splashes or sudden drops, ViewSonic’s TD3207 is a durable, rugged device built to endure heavy activity and unpredictable weather conditions. Featuring a 3mm thick glass with 7H hardness, the scratch and water-resistant surface will capture the smallest touch to the biggest swipe with ease.
Intuitive and responsive touch
Experience a smooth, responsive interactive touchscreen at your fingertips with the hyper-sensitive Projective Capacitive (PCAP) Touch Technology. With up to 10 touch points at a time, each touch response is read accurately and with precision.
Long-lasting usage
Capable of 24/7 continuous operation, the TD3207 is the ideal device to run graphics-rich content in high-traffic spaces for long days and evenings.
VESA-mountable design in any space and direction
Equipped with 200x100mm & 400x200mm VESA-mountable designs, the open-framed display can be attached to any surface seamlessly and securely. Horizontal, vertical or face-up, it can be installed in various orientations to suit your preferred venue and viewing angle.
SuperClear ® AMVA technology
Enhanced with SuperClear® AMVA panel technology, be captivated by the ultra-realistic picture quality and more authentic colors from every viewing angle.
Brilliance at its brightest
With up to 450 nits of brightness, the screen delivers greater clarity to the tiniest detail and constant visuals in a brighter environment. Group collaborations and presentations to larger audiences are now elevated into an immersive visual experience.
Real time at your disposal
Maximize efficiency with the smart time-bound system that allows real-time scheduling and allocated programming down to your preferred second. It runs smooth and tight like clockwork, so you don’t have to.
Connectivity at your command
Streamline your workflow with unmatched device-sharing capabilities. Using an array of cable inputs like HDMI and DisplayPort, connect to external consoles, laptops, or high-definition devices, and share your content effortlessly. And an RS232 In connection allows you can control the device remotely.
| Beeldscherm | |
| Beeldschermdiagonaal | 81,3 cm (32") |
| Resolutie | 1920 x 1080 Pixels |
| HD type | Full HD |
| Oorspronkelijke beeldverhouding | 16:9 |
| Display technologie | LED |
| Soort paneel | VA |
| LED backlight | Ja |
| Backlight type | LED |
| Touchscreen | Ja |
| Touchscreen technologie | Capacitief |
| Touch technologie | Multi-touch |
| Hoeveelheid simultane aanraakpunten | 10 |
| Helderheid | 450 cd/mý |
| Responstijd | 5 ms |
| Beeldscherm vorm | Flat |
| Typische contrastverhouding | 3000:1 |
| Contrast ratio (dynamisch) | 50000000:1 |
| Maximale refresh snelheid | 60 Hz |
| Kijkhoek, horizontaal | 178ø |
| Kijkhoek, verticaal | 178ø |
| Beeldscherm, aantal kleuren | 16.78 miljoen kleuren |
| Pixel pitch | 0,364 x 0,364 mm |
| Frequentiebereik horizontaal | 15 - 73 kHz |
| Frequentiebereik verticaal | 47 - 75 Hz |
| Digitale horizontale frequentie | 15 - 73 kHz |
| Digitale verticale frequentie | 47 - 75 Hz |
| Hardheid oppervlak | 7H |
| Kleurstandaard gamut | NTSC |
| Kleurbereik | 72 procent |
| Prestatie | |
| NVIDIA G-SYNC | Nee |
| AMD FreeSync | Nee |
| Multimedia | |
| Aantal luidsprekers | 2 |
| Ingebouwde luidsprekers | Ja |
| Design | |
| Glas dikheid | 3 mm |
| Poorten & interfaces | |
| Type USB-upstreampoort | USB Type-B |
| Aantal upstream-poorten | 1 |
| HDMI | Ja |
| Aantal HDMI-poorten | 1 |
| HDMI versie | 1.4 |
| Aantal DisplayPorts | 1 |
| Audio-uitgang | 1 |
| RS-232 port | 1 |
| Ergonomie | |
| VESA-montage | Ja |
| Energie | |
| Energie-effici‰ntieklasse (SDR) | E |
| Energieverbruik (SDR) per 1000 uur | 25,8 kWu |
| Stroomverbruik (typisch) | 43 W |
| Stroomverbruik (in standby) | 0,5 W |
| Vermogensverbruik (max) | 45,5 W |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Soort voeding | AC |
| Energie-effici‰ntieschaal | A tot G |
| Europees Productregister voor Energielabeling (EPREL) code | 416754 |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 20 - 90 procent |
| Gewicht en omvang | |
| Breedte apparaat (met standaard) | 747 mm |
| Diepte apparaat (met standaard) | 451 mm |
| Hoogte apparaat (met standaard) | 64 mm |
| Gewicht (met standaard) | 12,8 kg |
| Breedte ( zonder voet ) | 747 mm |
| Diepte ( zonder voet ) | 451 mm |
| Hoogte (zonder voet ) | 64 mm |
| Gewicht (zonder voet) | 12,8 kg |
| Verpakking | |
| Breedte verpakking | 863 mm |
| Diepte verpakking | 163 mm |
| Hoogte verpakking | 577 mm |
| Gewicht verpakking | 15,5 kg |
| Overige specificaties | |
| Internationale veiligheidscode (IP) | IP54 |
| Gewicht | 12,8 kg |
| Certificering | Regulations: CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, UKCA |
| Logistieke gegevens | |
| Pallet brutobreedte | 120 cm |
| Pallet brutolengte | 100 cm |
| Pallet brutohoogte | 187 cm |
| Hoeveelheid per (buitenste) hoofdverpakking | 1 stuk(s) |
| Code geharmoniseerd systeem (HS) | 8528521000 |
| Warranty | |
| Base Warranty | Non Non |
