APS Power Distribution 4XC19 / 4xC13 Output
ITCurry #: N6413701 | Article #: PD2-200-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The Vertiv Liebert POD PD2-200 is a power output distribution (POD) unit with built-in maintenance bypass feature. Designed for the GXT4 8-10kVA & GXT5 16-20kVA uninterruptible power supply (UPS) models, it is a POD that allows you to conduct UPS maintenance or replacements without power interruption to the connected load. It also automatically transfers the current from the UPS to the original power source in cases of UPS failures, saving your equipment from unnecessary downtimes and ensuring continuous uptime for your system. The PD2-200 is a plug-and-play unit that will replace the existing POD box on your UPS. It has four (4) IEC320-C19 and four (4) IEC320-C13 output connectors and is equipped with a Hardwire 3W + G(L-L-N-G) input connector. It also has circuit breakers and supports a max current of 63A.
| Design | |
| Soort | Eenfasig |
| Kleur van het product | Zwart |
| Poorten & interfaces | |
| Aantal AC uitgangen | 8 AC-uitgang(en) |
| Stopcontacttypes | C13 stekker, C19 stekker |
| Energie | |
| Stroom (max.) | 63 A |
| Gewicht en omvang | |
| Breedte | 188 mm |
| Hoogte | 145 mm |
| Gewicht | 2 kg |
| Verpakking | |
| Gewicht verpakking | 3 kg |
| Breedte verpakking | 302 mm |
| Diepte verpakking | 522 mm |
| Hoogte verpakking | 220 mm |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 40 øC |
| Temperatuur bij opslag | -20 - 60 øC |
| Luchtvochtigheid bij opslag | 0 - 95 procent |
| Hoogte, in bedrijf | 0 - 3000 m |
| Technische details | |
| Duurzaamheidscertificaten | RoHS |
| Certificaten van naleving | RoHS |
| Warranty | |
| Base Warranty | Non Non |
